W01-358-7443 Rubber Bellows 22C-1.5 Industrial Air Spring For Ridewell 1003587443C

China W01-358-7443 Rubber Bellows 22C-1.5 Industrial Air Spring For Ridewell 1003587443C supplier

Large Image :  W01-358-7443 Rubber Bellows 22C-1.5 Industrial Air Spring For Ridewell 1003587443C

Product Details:

Place of Origin: Guangdong,China
Brand Name: GUOMAT
Certification: ISO/TS16949:2009
Model Number: 2B7443

Payment & Shipping Terms:

Minimum Order Quantity: 1pc
Packaging Details: strong carton box or as customers need
Delivery Time: 2-8 work days
Payment Terms: T/T, Western Union,Paypal or Others
Supply Ability: 1000pcs/week
Contact Now
Detailed Product Description
Material: Steel Cover Plate , Rubber Bellows FIRESTONE: W01-358-7443
GOODYEAR FLEX: 2B12-305 Contitech: FD330-30 323
Top Cover Plate Screw (Nut) Tooth: 2 Pcs X 3/8-16UNC Rubber Bellows Natural Diameter: 300 Mm
Pressure Ability: 0.2-0.8 MPa

W01-358-7443 Rubber Bellows 22C-1.5 Industrial Air Spring For RIDEWELL 1003587443C





BELLOW Number COMPLETE Number COMPLETE Number

FIRESTONE W01 358 0259   DUNLOP (FR) S12280
22-1,5/095.0092 FIRESTONE W01 358 7443 FIRESTONE W01-358-7443
GOODYEAR FLEX 556 2 3 8328 GOODYEAR 2B12-305 GOODYEAR 2B12-305
578 92 3 310   AIRKRAF T 113493
AIRKRAFT 114302
  FIRESTONE FLEX 22-1,5







Specifications

2B-320 Rubber bellow only



Nut / Blind Nut

Top Cover Plate Screw (Nut) Tooth : 2 pcs X 3/8-16UNC

Screw Center Distance of Top Cover Plate : 157.5 mm

Bottom Cover Plate Screw (Nut) Tooth : 2 pcs X 3/8-16UNC

Screw Center Distance of Bottom Cover Plate : 157.5 mm

Gas Hole / Air inlet / Air Fitting

Gas Hole / Air inlet : 1/4NPTF / 3/4NPTF / Rp1/4

Rp1/4(Air inlet is in the center)

1/4NPT ( air inlet 73mm)

1/4NPT(Air inlet is in the center)

3/4NPT ( air inlet 73mm)

Cover Plate

Top Cover Plate Diameter (Width): 210 mm

Bottom Cover Plate Diameter (Width): 210 mm

Rubber Bellows

Rubber Bellows Natural Diameter : 300 mm

Rubber Bellows Natural Height : 241 mm

Bumper block / Buffer block

Without Bumper Block

Girdle Hoop / Girdle Ring

With Girdle Hoop :One Pieces of Girdle Hoop





Air Spring Supplier: ContiTech
Competitor / Supplier Number: FD330-30369

Air Spring Supplier: Goodyear
Reference: 578923315
Competitor / Supplier Number: 2B12-416

Air Spring Supplier: Goodyear
Reference: 578923310
Competitor / Supplier Number: 2B12-446

Air Spring Supplier: Triangle
Reference: 6328
Competitor / Supplier Number: 4369

Suspension of supplier: Hendrickson
FSIP OEM: W01-455-7443

Suspension of suppliers: Hendrickson Trailer
Competitor / Supplier Number: S9830

Suspended supplier: Ridewell
Competitor / Supplier Number: 1003587443C

Firestone Trimmed: w01-358-7443
