Rubber 2B6-833 Goodyear Air Spring Bellows 579-92-3-510

Rubber 2B6-833 Goodyear Air Spring Bellows 579-92-3-510

  • Rubber 2B6-833 Goodyear Air Spring Bellows 579-92-3-510
  • Rubber 2B6-833 Goodyear Air Spring Bellows 579-92-3-510
  • Rubber 2B6-833 Goodyear Air Spring Bellows 579-92-3-510
  • Rubber 2B6-833 Goodyear Air Spring Bellows 579-92-3-510
Rubber 2B6-833 Goodyear Air Spring Bellows 579-92-3-510
Product Details:
Place of Origin: Guangdong,China
Brand Name: Goodyear
Certification: ISO/TS16949:2009
Model Number: 2B6-833
Payment & Shipping Terms:
Minimum Order Quantity: 1pc
Packaging Details: strong carton box or as customers need
Delivery Time: 2-8 work days
Payment Terms: T/T, Western Union,Paypal or Others
Supply Ability: 1000pcs/week
Contact Now
Detailed Product Description
Material: Rubber And Aluminum Plate Goodyear: 2B6-833
Warranty: 12 Months Weight: 2.5 Kg
Other Name: Air Suspension Shock Absorber Pressure Ability: 0.2-0.8 M Pa
Rubber Bellows: 579923510
High Light:

2B6-833

,

579-92-3-510

,

Double Convoluted Rubber Shock Absorber

2B6-833 Goodyear Air Spring Bellows 579-92-3-510 Auto Parts Double Convoluted Rubber Shock Absorber





The specifications of the Goodyear 2B6-833 air spring are different from other double-layer traditional models because the 2B6-833 Goodyear air spring’s folding design and sleeve bellows have twice the Goodyear air spring reduction vibrator. They will provide similar features and functions, but in the sleeve type, the end cap bracket is permanently fixed by pinching the elastic member between the end cap bracket and the external crimping ring. The material used for the cover plate holders at both ends of the Goodyear 2B6-833 air spring is aluminum alloy, which is more corrosion-resistant than iron and lasts longer.





2B6-833 OEM Original Manufacturer:



Goodyear Original Part NO.:2B6-833;

Goodyear Original Part NO.:2B6 833;

Goodyear Original Part NO.:2B6833

Goodyear Flexmember Part NO.:579-92-2-833;

Goodyear Flexmember Part NO.:579 92 2 833;

Goodyear Flexmember Part NO.:579922833

Goodyear Bellows Part NO.:579-92-3-510

Goodyear Bellows Part NO.:579 92 3 510

Goodyear Bellows Part NO.:579923510





Specification of 2B6-833 Goodyear Air Spring:



Bellow Type: Double
Goodyear Bellow #: 579-92-3-510
Bottom Plate/Pison Type:
Top Plate Hole/Stud Qty: 2
Top Plate Dia: 4.15
Top Plate C to C Diameter: 2.75
Bottom Plate Hole Stud Qyt: 2
Bottom Plate Dia: 4.15
Bottom Plate C to C Diameter: 2.75
Bottom Plate Alignment: Parallel
Bumper: No
Bracket:
Min Height: 2.8
Max Height: 9.1





Other kinds of Goodyear Air Spring:



57992283000019 20106784 Y ENIDINE YI-2B6-830 ENIDINE YI-2B6-830
2B6-833 20095600 N 2B6-833 2B6-833
57992283300019 20095601 Y ENIDINE YI-2B6-833 METRIC ENIDINE YI-2B6-833 METRIC
57992283500019 20257581 Y ENIDINE YI-2B6-835 ENIDINE YI-2B6-835
57992283900000 20054211 Y 2B6-839 M 2B6-839 M
2B7-840 20316800 N 2B7-840 2B7-840
57992284000019 20117075 Y ENIDINE YI-2B7-840 ENIDINE YI-2B7-840
57992284100090 20811618 Y C 2B6-839 M C 2B6-839 M
57992284200000 20069561 Y KUHN 2B7-842 M KUHN 2B7-842 M
2B7-843 20588389 N 2B7-843 M 2B7-843 M
2B8-850 20095602 N 2B8-850 METRIC 2B8-850 METRIC
57992285000019 20095603 Y ENIDINE YI-2B8-850 ENIDINE YI-2B8-850
57992285300000 20221915 Y KUHN 2B8-853 (METRIC) KUHN 2B8-853 (METRIC)
2B8-854 20054212 N 2B8-854 M 2B8-854 M
57992285600090 20806001 Y C 2B8-854 C 2B8-854
57992351100000 20109236 Y 2B6-REG AIR LIFT G5814 FLEXMEMBER 2B6-REG AIR LIFT G5814 FLEXMEMBER
57992351500011 20295315 Y 2B6-EXT ARNOTT FLEXMEMBER 2B6-EXT ARNOTT FLEXMEMBER
57992351600000 20095608 Y 2B6 EXT SLEEVE G5813 AIR LIFT 2B6 EXT SLEEVE G5813 AIR LIFT
57992351800000 20177365 Y 2B6-EXT AIR LIFT 5817 FLEXMEMBER 2B6-EXT AIR LIFT 5817 FLEXMEMBER
57992352000000 20109238 Y 2B7 AIR LIFT MSB FLEXMEMBER 2B7 AIR LIFT MSB FLEXMEMBER
57992352200000 20168398 Y 2B7-REG AIR LIFT 5815 FLEXMEMBER 2B7-REG AIR LIFT 5815 FLEXMEMBER
57992352300000 20177366 Y 2B7-REG AIR LIFT 5818 FLEXMEMBER 2B7-REG AIR LIFT 5818 FLEXMEMBER
57992353200000 20439364 Y 2B8 SLD GRDL RNG - FOR COSTING 2B8 SLD GRDL RNG - FOR COSTING



Rubber 2B6-833 Goodyear Air Spring Bellows 579-92-3-510 0Rubber 2B6-833 Goodyear Air Spring Bellows 579-92-3-510 1Rubber 2B6-833 Goodyear Air Spring Bellows 579-92-3-510 2
