W01-M58-7894 Metric Firestone Air Spring Contitech FD 200-19 P04 Phoenix SP2B12R5 For Pirelli T2086660

W01-M58-7894 Metric Firestone Air Spring Contitech FD 200-19 P04 Phoenix SP2B12R5 For Pirelli T2086660

  • W01-M58-7894 Metric Firestone Air Spring Contitech FD 200-19 P04 Phoenix SP2B12R5 For Pirelli T2086660
W01-M58-7894 Metric Firestone Air Spring Contitech FD 200-19 P04 Phoenix SP2B12R5 For Pirelli T2086660
Product Details:
Place of Origin: Guangdong,China
Brand Name: GUOMAT
Certification: ISO/TS16949:2009
Model Number: 2B7894
Payment & Shipping Terms:
Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: strong carton box or as customers need
Delivery Time: 2-8 work days
Payment Terms: T/T, Western Union,Paypal or Others
Supply Ability: 1000pcs/week
Contact Now
Detailed Product Description
Material: Steel Cover Plate , Rubber Bellows Firestone: W01-M58-7894
Gas Hole: G1/4 Screw Tooth: 2XM10X1.5
Screw Center Distance: 89 Mm Cover Plate Diameter: 160 Mm
Pressure Ability: 0.2-0.8 M Pa Stroke: 75~260 Mm
Net Weight: 3.35 Kg Package Size: 24*24*24 CM
High Light:

W01-M58-7894

,

SP2B12R5 Metric Firestone Air Spring

,

T2086660 Firestone Air Spring

W01-M58-7894 Metric Firestone Air Spring Contitech FD 200-19 P04 Phoenix SP2B12R5 For Pirelli T2086660





Application of GUOMAT 2B7894 Air Spring:



GUOMAT 2B7894 Air Springs are widely used to automatically adjust the air suspension of commercial vehicles, trucks, trailers, buses, railway vehicles, mechanical equipment and building foundations. Gas springs are also called support rods, angle adjusters, pneumatic rods, shock absorbers, etc. According to the structure and function of the gas spring, there are several types of gas spring, such as free gas spring, self-locking gas spring, and traction. Gas spring, free stop gas spring, swivel chair gas spring, gas rod, shock absorber, etc. GUOMAT 2B7894 Air Spring This product is widely used in automobile, aviation, medical equipment, furniture, machinery manufacturing and other fields.





GUOMAT 2B7894 Air Spring Cross others OEM



OEM Reference OEM Reference

Goodyear:2B9-287
Goodyear:2B9
287
Goodyear:2B9287
Goodyear:578-92-3-202

Goodyear:578 92 3 202

Goodyear:578923202

Taurus: Kf216
Triangle Spring: 4320 SAF 4.229.1004.00 :SAF HOLLAND 4.229.1004.00

Firestone: 7894

Firestone:W01-358-7894

Firestone:W01 358 7894

Firestone:W013587894

Sirco: AS-6910
ContiTech: 64267

ContiTech:FD 200-19 P04 1/4 M10

ContiTech:FD 20019 P04 1/4 M10

ContiTech:FD 200 19 P04 1/4 M10

Pirelli T2086660
R & S Truck: 1027405 Euclid/Meritor Aftermarket: E-FS6910
Ridewell: 1003586910C ContiTech: FD200-19320
Batco: 10-96910 Euclid/Meritor Aftermarket: FS6910
Reyco: 23704-01 BWP: M-3501
Hendrickson: 45843-3 HD America: PMABG-6910B
Navistar/IHC: 554783C1 Ridewell: S4512C
UCF/Impex: AB-2B9-200 Leland: SC201
Automann: ABSP2B12R-6910 Leland: SC2011
Watson & Chalin: AS0001 Granning: 1371



AIRTECH
140013
AIRTECH PROD. NO.
113002
AUTOMINT
407
BL ACKTECH
2C21-210 P22
CONTINENTAL
FD 200-19 P04
CONTITECH
2682045000
DUNLOP FRANCE
S09208
FIRESTONE REF.
W01 M58 7894
STYLE NO.
T20
GOODYEAR
2B9-223
GRANNING
15599
PHOENIX
SP2B12R1
PIRELLI
86660
PIRELLI ARTICLE NO.
S09208 (9"1/4X2NB)
SPRINGRIDE
20F
TAURUS
KF 216 KF 218-6910
TYPE
CONV.
WABCO
951809 201 0



2B9-200 Goodyear Air Spring Technical parameters



Nut / Blind Nut



Top plate screw (nut) teeth: 2XM10X1.5
The screw center distance of the top cover plate: 89 mm
Screw (nut) teeth of the bottom cover plate:
2XM10X1.5
Screw center distance of bottom cover plate: 89 mm



Gas Hole / Air inlet / Air Fitting

Gas Hole / Air inlet : G1/4

Screw Center Distance Between Gas Hole and Nut : 44.5 mm



Cover Plate

Top Cover Plate Diameter: 160 mm

Bottom Cover Plate Diameter: 160 mm



Rubber Bellows

Rubber Bellows MAX Diameter: 251 mm

Rubber Bellows Natural Diameter : 224 mm

The Working Stroke : MIN 75 mm to MAX 260 mm

Maximum Height : 274 mm

Minimum Height :95mm

Stroke Height : 179mm



Bumper block / Buffer block

Without Bumper Block



Girdle Hoop / Girdle Ring

With Girdle Hoop :One Pieces of Girdle Hoop





The drawing of Goodyear Air Spring 2B9-200:









Goodyear #: 2B9-287
Bellows type:  double
Ultraman Bellows #: SP2B12R5
Flint Bellow #: 20F is 20
Goodyear Bellows #: 578-92-3-202
Contitech bellows #: FD 200-19 P04
Triangle bellows #: 6325

Number of top plate holes / studs: 3
Top plate diameter: 6.4 inch 162.56 mm
Top plate C to C diameter: 3.5 inch 88.9 mm

Base plate diameter: 6.4 inch 162.56 mm
Base plate C to C diameter: 3.5 inch 88.9 mm

Minimum height: 3.2 3.2 inch 81.28 mm
Maximum height: 10.8 10.8 inch 274.32 mm







Goodyear Part # Firestone Part # ContiTech Part # Contitech Order #
2B9-200 W01-358-6910 FD 200-19 320 64267
2B9-201 W01-358-6935 FD 200-19 499 64515
2B9-206 W01-358-6905 FD 200-19 315 64510
2B9-210 W01-358-6908 FD 200-19 362 64511
2B9-216 No Cross No Cross No Cross
2B9-218 W01-358-6927 FD 200-25 453 64553
2B9-225 W01-358-6928 No Cross No Cross
2B9-229 W01-358-6897 FD 200-19 505 64517
2B9-230 W01-358-6940 FD 200-19 450 64513
2B9-239 W01-358-6902 FD 200-19 310 64509
2B9-240 W01-358-7119 No Cross No Cross
2B9-244 No Cross No Cross No Cross
2B9-245 W01-358-7788 FD 200-19 510 64519
2B9-246 W01-358-6932 FD 200-19 452 64514
2B9-250 W01-358-6943 FD 200-25 426 64549
2B9-251 W01-358-6948 FD 200-25 429 64552
2B9-252 W01-358-6944 FD 200-25 454 64554
2B9-253 W01-358-6945 FD 200-25 427 64550
2B9-254 W01-358-6946 FD 200-25 463 64555
2B9-255 W01-358-6947 FD 200-25 428 64551
2B9-265 W01-358-6941 FD 200-19 448 64512
2B9-266 W01-358-6944 FD 200-25-454 64554
2B9-270 No Cross No Cross No Cross
2B9-280 W01-358-6941 FD 200-19 448 64512
2B9-288 W01-358-6926 FD 200-19 504 64516
2B9-296 No Cross No Cross No Cross
2B9-606 No Cross No Cross No Cross
2B9-607 No Cross No Cross No Cross
2B9-611 No Cross No Cross No Cross
2B9-614 No Cross No Cross No Cross
