| Place of Origin: | GUANGZHOU CHINA(MAIN LAND) |
| Brand Name: | GUOMAT |
| Certification: | ISO/TS16949:2009 |
| Model Number: | 1T9541 |
| Minimum Order Quantity: | 1 PCS |
|---|---|
| Price: | ＄59 |
| Packaging Details: | CARTON/CARTONS |
| Delivery Time: | 5-10 work days |
| Payment Terms: | T/T, L/C,PayPal |
| Supply Ability: | 1000 |
| TYPE: | ROLLING LOBE AIR SPRING | CONTITECH: | 99-10P861 |
|---|---|---|---|
| MATERIAL: | NATRAL RUBBER | PACKAGE: | STRONG CARTONS |
| MODEL: | TRUCK | WARRANTY: | 12 MONTHS |
| CONDITION: | NEW | PISTON: | WITH PISTON |
| Kenworth: | C81-1005 | ||
| High Light: | Contitech 99-10P861 Suspension Air Spring,Kenworth C81-1005 Suspension Air Spring,Airglide 460 Suspension Air Spring |
||
CONTITECH 99-10P861 Suspension Air Spring Kenworth C81-1005 Airglide 460
Product Information
GUOMAT NO. : 1T9541
VEHICLE TYPE: Truck
POSITION: The Floating Bridge
OEM REFERENCES
| FIRESTONE 1T15LA-0 / | Top Plate Number:3174 |
| FIRESTONE W01 358 9541 / W01-358-9541 / W013589541 | Piston Number:9569 |
| FIRESTONE 1T15KW-0 / | CONTITECH 9 9-10 P 861 / 99-10P861 / 99-10P 861 |
| W01 358 9541 / W01-358-9541 / W013589541 | Contitech 66111 |
| FIRESTONE 1T15LA 0 / | Airtech 137422 / 39541 CPP |
| FIRESTONE 1T15LA0 | Automann AB1DK20H-9541 |
| FIRESTONE 1T15KW 0 / | FIRESTONE 1T15KW0 |
Continental ContiTech 9 9-10 P 861, ContiTech Order # 68357,
Kenworth C81-1005, Automann 1DK20H-9541,
Firestone No. W01-358-9541, Firestone Style 1T15LA-0,
FleetPride AS9541, Triangle AS-8861, TRP AS9541
VEHICLE OEM REFERENCES
KENWORTH C81-1005
Kenworth Number:C81-1005
Kenworth C811005
Airglide 200 05/05/03 or later
Airglide 460
Airglide 690
Technical Parameters
Extended Height:11.80
Compressed Height: 6.25
Top Plate Width:9.00
Piston Width:8.18
Assembly Weight: 11.5 lbs
Design Height: 6-7 inches
Minimum Jounce Height: 3.75 inches
Maximum Rebound Height: 11.5 inches
Loading Capacity at 20 psig: 1,320 lbsf
Loading Capacity at 60 psig: 3,960 lbsf
Loading Capacity at 90 psig: 5,940 lbsf
Natural Frequency: Hz
Maximum Diameter: 11.7 inches
Material Type: N/A
Operating Temperature: 57Co to -54Co
ABOUT US...
Guangzhou Guomat Air Spring CO., Ltd.is located in Guangzhou, about 15min’s drive from BAIYUN AIRPORT. Our mainly products air spring, rubber bellow, air suspension compressor and refitted suspension system. They are widely used in bus, truck, cabin, vehicles’ seat, luxurious car and industrial machine field.
Our goal is to make your choice easier and save your money. We serve customers world-wide by offering quality goods at unbeatable prices, all while maintaining a focus on superior customer service. PLEASE FEEL FREE TO ASKANY QUESTIONS. All questions will be answered promptly (usually in less than 24 hours except weekends and holidays)
Give us your trust and we'll help you to repair or update your car!
The warranty period of Air Spring
GUOMAT air spring made of high quality materials(natural rubber), the warranty period of One Year.
Our air spring provides high performance and dynamics while ensuring perfect grip and maximum driving comfort in any case. In addition to improving the stability of the vehicle, they can reduce the number of vibratory movements due to road defects to optimize the comfort of passengers and allow you to ride smoothly.
Our dampers are designed to provide excellent ride quality by quickly adjusting to different road and vehicle conditions while providing ultimate safety and functionality.
