| Place of Origin: | GuangDong, China |
| Brand Name: | GUOMAT |
| Certification: | ISO/TS16949:2009 |
| Model Number: | 16X3 |
| Minimum Order Quantity: | 6PCS |
|---|---|
| Price: | $79.9-159.9/pc |
| Packaging Details: | Strong Carton Box Or As Customers Need |
| Delivery Time: | 2-8 work days |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 1000pcs/week |
| Name: | Rubber Air Spring | Spring Material: | Rubber + Steel |
|---|---|---|---|
| Product Warranty: | 12 Months | Condition: | Brand-New |
| Part Number: | SP2141 | Spring Type: | Triple Convoluted Type |
| Air Hole: | G1/2 | ||
| High Light: | FT816-40 Triple Convoluted Air Spring,Industrial Triple Convoluted Air Spring,Contitech Triple Convoluted Air Spring |
||
FT816-40 DS G1/2 Contitech Triple Convoluted Air Spring 16X3 Dunlop Industrial Suspension Air Actuator
Product Description
Parker Air Spring 9109177
Norgren Air Spring M/31163
Norgren Air Spring M31163
Norgren Air Spring M 31163
Contitech Air Spring FT816-40
Contitech Air Spring FT 816-40
Contitech Air Spring FT816-40 DS
Contitech Air Spring FT 816-40 DS
Contitech Air Spring FT816-40 DS G1/2
Contitech Air Spring FT 816-40 DS G1/2
Firestone Air Spring W01R584068
Firestone Air Spring W01 R58 4068
Firestone Air Spring W01-R58-4068
Dunlop Air Spring SP2141
Dunlop Air Spring SP 2141
Dunlop Air Spring 16X3 ; 16''x3
FT816-40 Rubber Air Bellow Technical Parameters
1.Top Cover Plate Diameter: Ø310mm
2. Bottom Cover Plate Diameter: Ø310mm
3. Air Inlet: G1/2
4. The Stud of Top Cover Plate : 4XM10
5. The Stud of Bottom Cover Plate : 4XM10
6. The Distance Between the Top Cover Stud: Ø282.5mm
7. The Distance Between the Bottom Cover Stud: Ø282.5mm
8. Rubber Bellow Max Diameter: Ø430mm
9. Suitable for Installation Width: Ø455mm
10. Max. Height: 550mm
11. Min. Height: 120mm
|
Pneumatic Applications - Static Eigenvalues ----Force F [kN] |
||||||||
| Pressure P [bar] | 3 | 4 | 5 | 6 | 7 | 8 | Volume V ［I］ | |
| Height H [mm] | 450 | 16.1 | 21.8 | 27.6 | 33.8 | 40.2 | 46.8 | 43 |
| 400 | 19.1 | 25.6 | 32.2 | 39.3 | 46.5 | 53.8 | 39 | |
| 350 | 21.5 | 28.8 | 36.2 | 44 | 51.9 | 60 | 35 | |
| 300 | 24.1 | 32.2 | 40.5 | 49.2 | 58.2 | 57.4 | 31 | |
| 250 | 27.1 | 36.3 | 45.5 | 55.2 | 65.1 | 75.2 | 27 | |
| 200 | 29.8 | 39.7 | 49.8 | 60.1 | 70.8 | 81.5 | 22 | |
| 150 | 31.4 | 41.8 | 52.3 | 63 | 73.8 | 84.8 | 18 | |
Other Contitech Triple Convoluted Air Spring
Triple Convoluted Air Bag FT 330-29
Triple Convoluted Air Bag FT 430-32
Triple Convoluted Air Bag FT 530-32
Triple Convoluted Air Bag FT 530-35
Triple Convoluted Air Bag FT 960-34
Triple Convoluted Air Bag FT 1330-35
Triple Convoluted Air Bag FT 330-29 546
Triple Convoluted Air Bag FT 330-29 547
Triple Convoluted Air Bag FT 330-29 520
Triple Convoluted Air Bag FT 330-29 430
Triple Convoluted Air Bag FT 330-29 431
Triple Convoluted Air Bag FT 330-29 432
Triple Convoluted Air Bag FT 330-29 433
Triple Convoluted Air Bag FT 330-29 469
Triple Convoluted Air Bag FT 330-29 466
Triple Convoluted Air Bag FT 330-29 498
Triple Convoluted Air Bag FT 412-323
Triple Convoluted Air Bag FT 210-32
Application of Air Springs in Industrial Equipment
In industrial production, a variety of mechanical equipment is used, and there are many parts inside these equipment. If one of the parts is damaged or missing, the machine cannot be used normally or even cannot be used. In order to prolong the service life of this mechanical equipment, an air spring can be installed to reduce the vibration of the mechanical equipment, thereby reducing friction between parts and prolonging the service life of the machine.
The Real Pictures
