| Place of Origin: | GuangDong, China |
| Brand Name: | GUOMAT |
| Certification: | ISO/TS16949:2009 |
| Model Number: | 1B9-223 |
| Minimum Order Quantity: | 6pcs |
|---|---|
| Price: | $99.9-159.9/pc |
| Packaging Details: | Strong Carton Box Or As Customers Need |
| Delivery Time: | 2-8 work days |
| Payment Terms: | T/T, Western Union, L/C |
| Supply Ability: | 1000pcs/week |
| Warranty: | 12 Months | Material: | Rubber + Iron |
|---|---|---|---|
| Origin: | Mexico | Brand: | GOODYEAR |
| Convolutions: | Double | Threaded Hole: | M10 |
| Style: | Convoluted Bellows | Type: | Complete Assembly |
| High Light: | Rubber Bellows Industrial Air Spring,2B9-223 Industrial Air Spring,578-92-3-211 Industrial Air Spring |
||
2B9-223 Rubber Bellows Industrial Air Spring 578-92-3-211 Double Convoluted Air Lift Suspension
Product Description
Original Manufacturer: GOODYEAR
Country of Origin: Mexico
Goodyear Spare Part Number: 2B9-223
Goodyear Spare Part Number: 2B9 223
Goodyear Spare Part Number: 2B 9-223
Goodyear Spare Part Number: 2B 9 223
Goodyear Rubber Bellows Number: 578923211
Goodyear Rubber Bellows Number: 578 92 3 211
Goodyear Rubber Bellows Number: 578-92-3-211
Manufacturer Part Number
MERITOR (ROR) Part Number: 21221395
MERITOR (ROR) Part Number: 21222663
WEWELER Part Number: US 06910F
HENDRICKSON Part Number: NA 1827
DISCOS Part Number: A 946 328 07 01
FLOOR Part Number: 13586
GRANNING Part Number: 1371
GRANNING Part Number: 15603
2B9-223 Goodyear Air Spring Technical Data
♦Top Cover Plate
Top Cover Plate Diameter: Ø162.5mm
Gas Hole/Air Fitting: 1/4''18NPTF
Threaded hole/Bolt: M10X1.5
Distance Between Threaded Holes: Ø89mm
Distance Between Threaded Hole and Air Hole: Ø44.5mm
♦Bottom Cover Plate
Bottom Cover Plate Diameter: Ø162.5mm
Threaded hole/Bolt: M10X1.5
Distance Between Threaded Holes: Ø89mm
♦Rubber Bellows
The Rubber Bellows Max.Diameter: 262
Design height: 215mm
Max.Height: 264mm
Min.Height: 81mm
Goodyear Double Convoluted Industrial Air Spring
|
Manufacturer |
Part No. |
Rubber Bellow No. |
Type |
|
GOODYEAR |
2B9-200 |
578-92-3-202 |
Air Spring Bellows |
|
GOODYEAR |
2B9-201 |
578-92-3-202 |
Air Spring Bellows |
|
GOODYEAR |
2B9-206 |
578-92-3-202 |
Air Spring Bellows |
|
GOODYEAR |
2B9-210 |
578-92-3-202 |
Air Spring Bellows |
|
GOODYEAR |
2B9-216 |
578-92-3-202 |
Air Spring Bellows |
|
GOODYEAR |
2B9-225 |
578-92-3-202 |
Air Spring Bellows |
|
GOODYEAR |
2B9-230 |
578-92-3-202 |
Air Spring Bellows |
|
GOODYEAR |
2B9-240 |
578-92-3-202 |
Air Spring Bellows |
|
GOODYEAR |
2B9-244 |
578-92-3-202 |
Air Spring Bellows |
|
GOODYEAR |
2B9-245 |
578-92-3-202 |
Air Spring Bellows |
|
GOODYEAR |
2B9-218 |
578-92-3-202 |
Air Spring Bellows |
|
GOODYEAR |
2B9-250 |
578-92-3-202 |
Air Spring Bellows |
|
GOODYEAR |
2B9-251 |
578-92-3-202 |
Air Spring Bellows |
|
GOODYEAR |
2B9-252 |
578-92-3-202 |
Air Spring Bellows |
|
GOODYEAR |
2B9-253 |
578-92-3-202 |
Air Spring Bellows |
|
GOODYEAR |
2B9-254 |
578-92-3-206 |
Air Spring Bellows |
|
GOODYEAR |
2B9-255 |
578-92-3-206 |
Air Spring Bellows |
|
GOODYEAR |
2B9-265 |
578-92-3-206 |
Air Spring Bellows |
|
GOODYEAR |
2B9-270 |
578-92-3-206 |
Air Spring Bellows |
|
GOODYEAR |
2B9-266 |
578-92-3-208 |
Air Spring Bellows |
|
GOODYEAR |
2B9-607 |
578-92-3-208 |
Air Spring Bellows |
|
GOODYEAR |
2B9-229 |
578-92-3-211 |
Air Spring Bellows |
|
GOODYEAR |
2B9-239 |
578-92-3-211 |
Air Spring Bellows |
|
GOODYEAR |
2B9-246 |
578-92-3-211 |
Air Spring Bellows |
|
GOODYEAR |
2B9-280 |
578-92-3-211 |
Air Spring Bellows |
|
GOODYEAR |
2B9-288 |
578-92-3-211 |
Air Spring Bellows |
|
GOODYEAR |
2B9-296 |
578-92-3-211 |
Air Spring Bellows |
|
GOODYEAR |
2B9-606 |
578-92-3-211 |
Air Spring Bellows |
|
GOODYEAR |
2B9-611 |
578-92-3-211 |
Air Spring Bellows |
|
GOODYEAR |
2B9-614 |
578-92-3-211 |
Air Spring Bellows |
|
GOODYEAR |
2B9-495 |
578-92-3-217 |
Air Spring Bellows |
The Real Pictures
