| Place of Origin: | GuangDong, China |
| Brand Name: | GUOMAT |
| Certification: | ISO/TS16949:2009 |
| Model Number: | 1T9287 |
| Minimum Order Quantity: | 6pcs |
|---|---|
| Price: | $79.9-99.9/pc |
| Packaging Details: | strong carton box or as customers need |
| Delivery Time: | 2-8 work days |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 1000pcs/week |
| Product Name: | Air Balloon | Sample: | Available |
|---|---|---|---|
| Warranty: | 1 Year | Material: | Rubber+Steel |
| Fitment: | Truck,Trailer, Semi-trailer | Firestone: | W01 358 9287 |
| Color: | Black | With Piston: | Yes |
| High Light: | Air Spring W01-358-9287,Air Spring For Hendrickson Truck |
||
Firestone Airide Replacement Air Spring W01-358-9287 1T15 Air Bellow For Hendrickson Truck
Product Details
GUOMAT 1T9287 is a high quality air spring designed for heavy duty trucks and trailers. . This air spring is designed to provide enhanced performance and ride comfort, making it ideal for heavy-duty applications.
| Cross References | |||
| Firestone | W01-358-9287 | Firestone | W01 358 9287 |
| Firestone | W013589287 | Firestone | 1T15 |
| Contitech | 910-17.5P406 | Goodyear | 1R12-424 |
| Goodyear | 1S12-027 | Triangle | 8406/6391 |
| Original Parts | |||
| Hendrickson Truck | 1991 and up | Hendrickson | 50405 |
| Hendrickson | 50405-1 | Hendrickson | 50405-2 |
| Hendrickson | 50898-2 | Note | Bracket 6042/6044-Nwe |
W01-358-9287 Firestone Air Spring
W01 358 9287 Firestone Air Spring
W013589287 Firestone Air Spring
WO1-358-9287 Firestone Air Spring
WO1 358 9287 Firestone Air Spring
WO13589287 Firestone Air Spring
1R12-424 Goodyear Air Spring
1R 12-424 Goodyear Air Spring
1R12 424 Goodyear Air Spring
566243097 Goodyear Air Bellow
566 24 3 097 Goodyear Air Bellow
566-24-3-097 Goodyear Air Bellow
1S12-027 Goodyear Air Spring
1S 12-027 Goodyear Air Spring
533241001 Goodyear Air Bellow
533 24 1 001 Goodyear Air Bellow
533-24-1-001 Goodyear Air Bellow
566241012 Goodyear Air Bellow
566 24 1 012 Goodyear Air Bellow
566-24-1-012 Goodyear Air Bellow
566241240 Goodyear Air Bellow
566 24 1 240 Goodyear Air Bellow
566-24-1-240 Goodyear Air Bellow
566243077 Goodyear Air Bellow
566 24 3 077 Goodyear Air Bellow
566-24-3-077 Goodyear Air Bellow
566243225 Goodyear Air Bellow
566 24 3 225 Goodyear Air Bellow
566-24-3-225 Goodyear Air Bellow
Here are some technical details about the Firestone W01-358-9287 Air Spring:
Order Number : W01-358-9287
Bellows #: 1T15M-8
Assembly Weight: 18.5 lbs
Design Height: 12.5-13.5 inches
Extended Height: 22.00 inches
Diameter: 10-1/8 in (25.73 cm)
Air Inlet: 1/4 in NPT
How to order ?
Step 1, please tell us what model and quantity you need;
Step 2,then we will make a PI for you to confirm the order details;
Step 3,when we confirmed everything ,you can arrange the payment;
Step 4,finally we deliver the goods within the stipulated time.
After Service and Packing
| After Service | Packing |
|
(1) Strict Testing before shipment (2) Follow up the customers' feedback (3) Quality Guarantee |
(1) Neutral packing (2) Customized packing |
If you are interested in our products , please Send your Inquiry Details in the Below, Click "Send" Now!!
The GUOMAT 1T9287 Truck Air Spring Real Picture
