Goodyear Air Spring Assembly No.: 1R14-757,1R 14-757,1R14 757
Dunlop Air Spring Assembly No.: D141444
Granning Air Spring Assembly No.: 16905
BPW Air Spring Assembly No.: 05.429.40.08.1
BPW Air Spring Assembly No.: 05.429.41.21.0
BPW Air Spring Assembly No.: 05.429.41.31.0
BPW Air Spring Assembly No.: 05.429.41.36.0
BPW Type No.: 05.429.43.41.0
IVECO: 500036830
How to Install Air Springs on a Heavy Truck Suspension
Installing air springs in a heavy truck's suspension system can significantly improve the vehicle's comfort and load-carrying capacity.
- Prepare Tools and Materials:
Make sure you have the proper tools, such as wrenches, screwdrivers, jacks, and struts.
Purchase an air spring kit that fits your truck model.
Lift the truck up using the jack and secure it with struts.
- Remove the Old Suspension:
Carefully remove the existing suspension components, especially the springs and shock absorbers. Make sure to record the location of each component so you can reinstall it.
Place the air spring in the designated location, making sure it is aligned with the connection points to the frame and suspension.
Secure the air spring in place using the provided hardware.
Connect the air hose according to the manufacturer's instructions, making sure there are no leaks.
After completing the installation, gradually inflate and check the air spring's operation.
Make sure all connections are secure and make any necessary adjustments to ensure optimal performance.
- Complete the Installation:
Reinstall the other suspension components, making sure all parts are securely fastened.
Check the effectiveness of the air springs by lowering the vehicle and conducting a road test.
Do Air Springs Require Regular Maintenance?
Yes, air springs do require regular maintenance. Regular maintenance can ensure the proper operation of the air spring and extend its service life.
| Check the air pressure: |
| Check the air pressure of the air spring regularly to ensure that it is within the manufacturer's recommended range. |
| Check the air pipe and joints: |
| Check the air pipe and connecting joints for signs of air leakage and ensure that they are well sealed. |
| Clean the Air spring: |
| Clean the air spring regularly to remove dirt and debris to prevent wear and corrosion. |
| Check the wear of the spring: |
| Check the appearance of the spring regularly to ensure that there are no cracks, damage or deformation. |
| Lubrication: |
| Properly lubricate the moving parts as needed to keep them running smoothly. |
