W013586927 Industrial Air Spring Rubber Bellows 20-2 For SAF Holland 57006927

Product Details:

Place of Origin:	Guangdong,China
Brand Name:	GUOMAT
Certification:	ISO/TS16949:2009
Model Number:	2B6927

Payment & Shipping Terms:

Minimum Order Quantity:	1pc
Packaging Details:	strong carton box or as customers need
Delivery Time:	2-8 work days
Payment Terms:	T/T, Western Union,Paypal or Others
Supply Ability:	1000pcs/week

Contact Now

Detailed Product Description

Material:	Steel Cover Plate , Rubber Bellows	Firestone:	W01356927
Gas Hole:	1/4NPT	Screw Tooth:	3/4-16UNF
Screw Center Distance:	89 Mm	Cover Plate Diameter:	160 Mm
Pressure Ability:	0.2-0.8 M Pa	Stroke:	81-325 Mm
Package Size:	242424 Cm
Highlight:	air helper springs , air suspension parts

W013586927 Industrial Air Spring Rubber Bellows 20-2 For SAF Holland 57006927

2B6927 Cross others OEM

OEM References Numbers	References Numbers
GUOMAT :2B6927 Firestone : W01-358-6927	Triangle : 6332/4453
Contitech : FD 200-25 453	Leland : Sc2072
Contitech :: 161336	SAF Holland : 57006927
Goodyear : 2B9-218	Tuthill Technology : 1290601
Goodyear : 578923206/2	Reyco : 12906-01

Airspring Supplier: ContiTech
Reference: 161336
Competitor / Supplier Number: FD20025453

Airspring Supplier: Goodyear
Reference: 578923206
Competitor / Supplier Number: 2B9218

Airspring Supplier: Triangle
Reference: 6332
Competitor / Supplier Number: 4453

Suspension Supplier: Leland
Competitor / Supplier Number: SC2072

Suspension Supplier: SAF Holland
Competitor / Supplier Number: 57006927

Suspension Supplier: Tuthill Technology
FSIP OEM: W017556927

Suspension Supplier: Tuthill Technology
Competitor / Supplier Number: 1290601

Firestone trimmed: w013586927

GUOMAT 2B6927 Technical parameters

❶Nut / Blind Nut

Top Cover Plate Screw (Nut) Tooth : 1pcsX 3/4-16UNF

Top Cover Plate Screw (Nut) is Combined with the (Gas Hole / Air inlet / Air Fitting) which is In The Middle Of The Top Cover Plate

Bottom Cover Plate Screw (Nut) Tooth : 2pcsX3/8-16UNC

Screw Center Distance of Bottom Cover Plate : 89 mm

❷ Gas Hole / Air inlet / Air Fitting

Gas Hole / Air inlet : 1/4 N P.T.F. / 1/4NPTF

❸ Cover Plate

Top Cover Plate Diameter: 160 mm / 6.31 inches

Bottom Cover Plate Diameter: 160 mm / 6.31 inches

❹Rubber Bellows

Rubber Bellows MAX Diameter: 262 mm

Rubber Bellows Natural Diameter :225 mm / 8.88 inches

The Working Stroke : MAX 325mm to MIN 81 mm

Maximum Height : 325 mm

Minimum Height :81 mm / 3.12 inches

Stroke Height : 224 mm

❺ Bumper block / Buffer block

With Bumper Block Or Without Bumper Block

❻ Girdle Hoop / Girdle Ring

With Girdle Hoop :One Pieces of Girdle Hoop

Firestone Part Number:W01-358-6927 / w013586927 / w01 358 6927

Firestone Bellows Number:20-2

ContiTech : FD20025453 / FD200-25453 FD200-25 453

ContiTech : 16133

Goodyear Part Number:2B9-218 / 2B9218 / 2B9 218

Goodyear Bellows Number:578-92-3-202 / :578923202 / :578 92 3 202

Reyco Number:12906-01

Triangle Part Number:4453

Triangle Bellows Number:6332

Leland : SC2072

SAF Holland : 57006927

Tuthill Technology : FSIP OEM: W017556927

Tuthill Technology : 1290601

Details Technical data at the below photo

Vibration isolation - dynamic characteristic values

Design height H: recommended 10 inch, minimum 9.06 inch
Pressure p [psi]	40	60	80	100	120	Vol. V [in.3]
Force (Load) [lbf]	1230	1890	2540	3190	3840
Spring rate [lbf/in.]	389	552	741	932	1080	538
Natural frequency [Hz]	1.8	1.8	1.7	1.7	1.7

Pneumatic application - static characteristic values Force F [kN]

Force F [lbf]
Pressure p [psi]		40	6 0	80	100	120	Vol. V [in.3]
Height H [in.]	11.0	948	1470	2000	2550	3110	560
	10.0	1180	1780	2430	3060	3720	540
	9.0	1370	2070	2780	3510	4240	510
	8.0	1530	2280	3070	3850	4640	470
	7.0	1670	2490	3340	4200	5030	440
	6.0	1790	2680	3570	4470	5360	400
	5.0	1880	2800	3750	4700	5570	350
	4.0	1960	2910	3910	4900	5750	300
