Hendrickson Trailer S-21323 Truck Air Spring Suspension Firestone W013586962

China Hendrickson Trailer S-21323 Truck Air Spring Suspension Firestone W013586962 supplier

Large Image :  Hendrickson Trailer S-21323 Truck Air Spring Suspension Firestone W013586962

Product Details:

Place of Origin: Guangdong,China
Brand Name: GUOMAT
Certification: ISO/TS16949:2009
Model Number: 2B6962

Payment & Shipping Terms:

Minimum Order Quantity: 1pc
Packaging Details: strong carton box or as customers need
Delivery Time: 2-8 work days
Payment Terms: T/T, Western Union,Paypal or Others
Supply Ability: 1000pcs/week
Contact Now
Detailed Product Description
Material: Iron Plate , Rubber Bellows Firestone: W01-358-6962
Gas Hole: 3/8NPTF Screw Center Distance: 86 Mm
Cover Plate Diameter: 160 Mm Pressure Ability: 0.2-0.8 M Pa
Stroke: 95-325 Mm Two Blind Nuts: 2X1/2-13UNC

Hendrickson Trailer S-21323 Truck Suspension Air Spring Firestone W013586962





GUOMAT 2B6960 Specifications and Technical Data



Compressed Height: 3.12 inches /

Top Cover Plate Diameter: 6.31 inches / 160mm

Bottom Cover Plate Diameter: 6.31 inches / 160mm

Screw Center Distance : 89 mm

Distance Gas Hole Between Nut: 44.5 mm

Top Cover Plate Screw (Nut) Tooth : 2X1/2-13UNC

Bottom Cover Plate Screw (Nut) Tooth : 2pcsX3/8-16UNC

One hole in the middle of the Bottom Cover Plate:10.3

Rubber Bellows MAX Diameter: 262 mm

The Working Stroke : MAX 325 mm to MIN 95 mm

Gas Hole / Air inlet : 1/4 NPTF

Firestone Bellows Number: 20-2

Goodyear Bellows Number: 578-92-3-206 / 578923206 / 578 92 3 206

Bellows NO.: 20-2

Assembly Weight: 8.1 lbs

Design Height: 9-11 inches

Loading Capacity at 20 psig: 648 lbsf

Loading Capacity at 60 psig: 1,944 lbsf

Loading Capacity at 90 psig: 2,916 lbsf

Maximum Diameter: 10.4 inches

Operating Temperature: 56Cº to -53Cº





Goodyear: 2B6962 Cross others OEM



GUOMAT NO.2B6962

Firestone:W01-358-6962

Firestone:W01 358 6962

Firestone:W013586962
Contitech : FD 200-25 511

Contitech :FD200-25 511

Contitech :FD20025 511

Goodyear Bellows: 578-92-3-206

Goodyear Bellows:578 92 3 206

Goodyear Bellows:578923206

Hendrickson Trailer Number:S-21323
Triangle Part Number:4511
Triangle Bellows Number:6332





Description and application Of GUOMAT 2B6962 air spring:



This kind of GUOMAT 2B6962 that has two Two Pillars Nuts at the top of the Cover Plate And Two Blind Nuts at the bottom of the Cover Plate. one Gas Hole / Air inlet 1/4 NPTF at the side of the top of the cover plate.This air spring can be used on trailers for retrofitting. At the same time can be used in many industrial equipment.It is very convenient to install.
