1R13-039 Goodyear Air Spring 566-26-3-051 For NEWAY 905-57-019

1R13-039 Goodyear Air Spring 566-26-3-051 For NEWAY 905-57-019

  • 1R13-039 Goodyear Air Spring 566-26-3-051 For NEWAY 905-57-019
  • 1R13-039 Goodyear Air Spring 566-26-3-051 For NEWAY 905-57-019
  • 1R13-039 Goodyear Air Spring 566-26-3-051 For NEWAY 905-57-019
  • 1R13-039 Goodyear Air Spring 566-26-3-051 For NEWAY 905-57-019
  • 1R13-039 Goodyear Air Spring 566-26-3-051 For NEWAY 905-57-019
  • 1R13-039 Goodyear Air Spring 566-26-3-051 For NEWAY 905-57-019
1R13-039 Goodyear Air Spring 566-26-3-051 For NEWAY 905-57-019
Product Details:
Place of Origin: GUANGZHOU CHINA(MAIN LAND)
Brand Name: Goodyear
Certification: ISO/TS16949:2009
Model Number: 1R13-039
Payment & Shipping Terms:
Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: CARTON/CARTONS
Delivery Time: 5-10 work days
Payment Terms: T/T, L/C,PayPal
Supply Ability: 1000
Contact Now
Detailed Product Description
TYPE: ROLLING LOBE AIR SPRING Goodyear: 1R13-039
MATERIAL: NATRAL RUBBER PACKAGE: STRONG CARTONS
MODEL: TRUCK WARRANTY: 12 MONTHS
CONDITION: NEW SITUATION: WITH PISTON
Goodyear BELLOWS NUMBER: 566263051
High Light:

1R13-039

,

566-26-3-051

,

905-57-019

1R13-039 Goodyear Truck Air Suspension Parts Truck Air Springs 566-26-3-051 For NEWAY 905-57-019





Product Information



Manufacturer: Goodyear
Brand name: Goodyear
Product weight:11 kilograms
Package size: 29 x 29 x 38 cm
Model:
1R13-039

VEHICLE TYPE: Truck

POSITION: The Floating Bridge





OEM REFERENCES



Goodyear  Flex. 566263051
Goodyear Flex. 566 26 3 051
Goodyear Flex. 566-26-3-051
Goodyear Part NO. 1R13-039
Goodyear Part NO. 1R13 039
Goodyear Part NO. 1R13039
FIRESTONE Part NO. W01-358-9121
FIRESTONE Part NO. W01 358 9121
FIRESTONE Part NO. W013589121
CONTITECH Part NO. 10 10-16 5 S 783 64746
CONTITECH Part NO. 1010-16 5S783 64746
CONTITECH Part NO. 1010-165S783 64746

UTOMANN NEWAY CONT.
AB1D28G-9121 905-57-083 AB1DK23K-9228 AR-1115-1-G
AB1DK25E-S783
CONTI
10 10-16 5 S 783 64746
DAYTON
352-9121
FIRESTONE
9121 W013589121





VEHICLE OEM REFERENCES



MERITOR MLF9025

HDA
PMABG-9123B
HENDRICKSON AS621-9121
B-3411 INT’L/NAVISTAR 8317
554773C1
LOAD GUARD
SC2040
NEWAY
905-57-019 905-57-052 905-57-078
TRIANGLE TRP
AS91210
WATSON & CHALIN AS-0013 AS-0083





The  Goodyear's of Air Spring



  Goodyear's sleeve-type air springs will use a flexible component without internal molded beads. Connect the flexure to the end of the holder by pinching the material between the end and the outer crimp ring and then adjusting it to the appropriate diameter. Goodyear sleeve airbag springs have many applications. The most common uses are passenger springs for cars and trucks, isolators and springs for truck cab suspensions and seat springs, and many common industrial applications. 1R13-118 Goodyear Super Air Cushion® Air Spring will provide your truck, trailer or bus with long-term durability and air suspension productivity, and provide years of maintenance-free service







ABOUT US...



Guangzhou Guomat Air Spring CO., Ltd.is located in Guangzhou, about 15min’s drive from BAIYUN AIRPORT.Our mainly products air spring, rubber bellow, air suspension compressor and refitted suspension system.They are widely used in bus, truck, cabin, vehicles’ seat, luxurious car and industrial machine field.
Our goal is to make your choice easier and save your money. We serve customers world-wide by offering qualitygoods at unbeatable prices, all while maintaining a focus on superior customer service. PLEASE FEEL FREE TO ASKANY QUESTIONS. All questions will be answered promptly (usually in less than 24 hours except weekends and holidays)
Give us your trust and we'll help you to repair or update your car!



1R13-039 Goodyear Air Spring 566-26-3-051 For NEWAY 905-57-019 01R13-039 Goodyear Air Spring 566-26-3-051 For NEWAY 905-57-019 1

1R13-039 Goodyear Air Spring 566-26-3-051 For NEWAY 905-57-019 21R13-039 Goodyear Air Spring 566-26-3-051 For NEWAY 905-57-019 3





Other kinds of goodyear:



Goodyear 13" 1R13 Diameter Rolling Lobe Air Springs

Part Number

Top Plate

Qty

Bottom Piston

Qty

Top Plate

Dia

Bottom Plate

Dia.

Collapsed

Height

Flexmember Piston

Piston

Type

1R13-038 2 4 10.3 10.2 8.9 566-26-3-072 566-20-7-097 S
1R13-039 2 4 10.3 10.2 7.7 566-26-3-051 566-20-7-096 S
1R13-047 2 4 10.3 10.2 7.7 566-26-3-051 566-20-7-096 S
1R13-048 2 4 8 8.9 566-26-3-072
1R13-049 2 4 10 7.7 566-26-3-051
1R13-053 2 4 10.3 10.1 6 566-26-3-051 566-20-7-036 A
1R13-070 2 1 7.7 9.25 7.6 566-26-3-015 566-20-7-084 A
1R13-075 2 4 10.3 10.1 6 566-26-3-051 566-20-7-036 A
1R13-097 2 4 10.3 9.5 5.6 566-26-3-081 566-20-7-124 S
1R13-109 2 4 10.3 9.5 5.6 566-26-3-081 566-20-7-124 S
1R13-115 2 4 9 10.13 9.4 566-26-3-044 566-20-7-006 A
1R13-116 2 4 9 10.13 8.9 566-26-3-044 566-20-7-006 A
1R13-117 2 4 9 10.2 7.7 566-26-3-043 566-20-7-080 C
1R13-118 1 4 10 10.2 7.2 566-26-3-068 566-20-7-127 S
1R13-119 3 4 9 9.5 5.6 566-26-3-053 566-20-7-106 S
1R13-120 2 4 11.3 11.8 5.7 566-26-3-054 566-20-7-076 A
1R13-124 2 4 10.3 10.2 7.3 566-26-3-050 566-20-7-127 S
1R13-130 2 1 10.3 9.5 4.6 566-26-3-055 566-20-7-210 C
1R13-133 2 2 10.3 8.1 4.6 566-26-3-056 566-20-7-210 S
1R13-152 2 1 10.3 9.8 7.5 566-26-3-071 566-20-7-235 C
1R13-153 2 1 10.3 9.8 9 566-26-3-071 566-20-7-237 C
1R13-155 2 1 10.3 9.8 9 566-26-3-071 566-20-7-106 S
1R13-159 2 1 10.3 8.8 6.1 566-26-3-073 566-20-7-154 C
1R13-176 2 1 10.4 8.8 9.1 566-26-3-078 566-20-7-154 C
1R13-177 2 1 10.4 8.8 9.1 566-26-3-080 566-20-7-154 C
1R13-181 2 4 10.3 9.5 5.6 566-26-3-051 566-20-7-124 S
1R13-182 2 4 10.3 9.5 5.6 566-26-3-051 566-20-7-152 S
1R13-188 2 1 10.4 9.9 7.8 566-26-3-078 566-20-7-152 C
