G1/2 Air Inlet 8" 203.2mm PM31082 Dunlop Air Spring

Product Details:

Place of Origin:	Guangdong,China
Brand Name:	Norgren
Certification:	ISO/TS16949:2009
Model Number:	PM/31082

Payment & Shipping Terms:

Minimum Order Quantity:	1pc
Price:	US$1.00-US$299.00/PC
Packaging Details:	strong carton box or as customers need
Delivery Time:	2-8 work days
Payment Terms:	T/T, Western Union,Paypal or Others
Supply Ability:	1000pcs/week

Contact Now

Detailed Product Description

Material:	Steel Cover Plate , Rubber Bellows	Bellows NO .:	Springride DF 8”x2
Norgren:	PM/31082	Plate Dia.:	184 Mm
Max Dia.:	225 Mm	Pressure Ability:	0.2-0.8 MPa
Air Inlet:	G1/2	Stroke:	150 Mm
Dunlop:	S08201
Highlight:	PM 31082 Dunlop Air Spring , 203.2mm Dunlop Air Spring , Double Convoluted Dunlop Pneuride Bellows

PM31082 Dunlop Air Spring 8"／203.2mm Stroke Length 185 mm Dunlop Pneuride Bellows 8”x2 S08201 Double Convoluted

PM／31082 Dunlop Replaces These Air Springs

Dunlop FR: 8”x2 S08201
Norgren: PM/31082 1 PM 31082 1 PM31082
Nominal 0 (inch) X convolutions: 8”x2/8”x2/8x2
Continental ContiTech: FD 120-17 CI G3/4
Continental ContiTech: FD 120-17 CI G3/4 M8
Continental ContiTech: FD 120-17 3/4 M8
Continental ContiTech: FD 120-17 CI 2682 030 000
Continental ContiTech Bellow: FD 120-17 /FD 120 171 FD12017
Goodyear: 2B8-2152 12B8 2152 12B82152
Goodyear Flex No.: 578-92-3-21511578 92 3 2151/ 5789232151
Festo: EB-215-155/ EB 215 1551 EB215155

PM／31082 Dunlop Specifications and Detail Technical Parameters:

Operation: Single acting
Stroke length: 185 mm
Port size: G3/4
Nominal diameter: 8"
Number of convolutions:

❶Nut / Blind Nut
Top Cover Plate Screw (Nut) Tooth : 4pcs X M10

Bottom Cover Plate Screw (Nut) Tooth : 4pcs X M10

❷ Gas Hole / Air inlet / Air Fitting
Gas Hole / Air inlet : G1/2

❸ Cover Plate
Top Cover Plate Diameter (Width): 184 mm

Bottom Cover Plate Diameter (Width): 184 mm

Material top and bottom plate:Steel

❹Rubber Bellows
Diameter max at 7 bar:225MM

Stroke of Rubber Bellows:75mm-225m

❺ Bumper block / Buffer block
Without Bumper Block
❻ Girdle Hoop / Girdle Ring
With Girdle Hoop :One Pieces of Girdle Hoop

max force at stroke 25 mm and 5 bar 12,3 kN
Rubber material Standard up to 70°C natural rubber

Medium:	Compressed Air
Port size:	G3/4
Operation:	Single acting
Operating pressure:	0 ... 8 bar
Operating temperature:	-30 ... 50 °C
Stroke length:	185 mm
Theoretical force:	16500 N
Range:	PM/31000

Other kinds of model air bellows:

W01-R58-4081 (2 3/4" x3)
W01-R58-4051 Dunlop Style 4,5 " x 2
W01-R58-4052 - (6" x1 steel)
Firestone W01-R58-4057 - (10 x1 steel)
Firestone W01-R58-4027 - 8x2 (Epichlorhydrin / Herclor)
Firestone W01-R58-4090 - 8"x2 Butyl
Firestone W01-R58-4055 - 8x2 Steel
Firestone W01-R58-4060 (12 x1 steel)
Firestone W01-R58-4077 (12 x1 Herclor )
Firestone W01-R58-4056 -8"x3 Steel
Firestone W01-R58-4062 (12 x3 Steel)
Firestone W01-R58-4065 (14 1/2 x3 Steel)
Firestone W01-R58-4098 (14 1/2 x1 Herclor)
Firestone W01-R58-4097 (14" 1/2 x2 Herclor)
Firestone W01-R58-4025 - (10" x1 Epichlorhydrin/Herclor)
Firestone W01-R58-4078 - (6 x1 Alu )
Firestone W01-R58-4070 - (6 x 2 Alu )
Firestone W01-R58-4053 - (6 x 2 Steel )
Firestone W01-R58-4059 - (10" x3 steel)
Firestone W01-R58-4054 - 8x1 Steel
Firestone W01-R58-4028 - 8"x1 Epichlorhydrin
Spar Part Bellow 8"x2 W01-R58-4045
Firestone W01-R58-4064 -14" 1/2 x2
Firestone W01-R58-4063 -14 1/2 x1
Bellow only 8" x 1 -- W01-R58-4085
Firestone W01-R58-4048
W01-R58-4080 - 2 3/4" x 2
Firestone W01-R58-4060- 12" x2 steel
Firestone W01-R58-4070 - (6 x 2 V2a )
Firestone W01-R58-4051E 4,5 x 2 Stainless Steel
Firestone W01-R58-4050
W01-R58-4080 - 2 3/4" x 1

Bellows	Type	Ø Plate	Ø Max.	Min. Height	Max. Height	Total Stroke	Static Height	ØC	Space Envelope	Weight in kg
Single layer	6x1	153	168	45	90	45	80	127	180	1.95
	8x1	184	230	47	120	73	90	156	240	3.05
	10 x 1	210	280	50	135	85	95	181	295	3.8
	12 x 1	260	330	50	145	95	95	232	345	4.75
	141⁄2 x 1	310	395	47	165	118	105	283	410	6.9
Double layer	6x2	153	168	73	170	97	120	127	180	2.25
	8x2	184	230	72	225	153	150	156	240	3.75
	91⁄4 x 2	197	260	70	240	170	160	168	275	4.5
	10 x 2	210	280	70	240	170	160	181	295	4.6
	12 x 2	260	330	74	240	166	160	232	345	5.85
	12 x 2E	260	345	75	400	325	270	232	370	6.9
	141⁄2 x 2	310	395	70	280	210	180	283	410	8.5
	16 x 2	310	430	77	320	243	180	283	445	8.8
Triple layer	6x3	153	168	105	255	150	180	127	180	2.55
	8x3	184	215	100	350	250	230	156	240	4.4
	10 x 3	210	280	100	365	265	235	181	295	5.4
	12 x 3	260	330	100	430	330	222	232	345	7.0
	141⁄2 x 3	310	395	100	476	376	280	283	410	10.0
	16 x 3	310	430	125	500	375	280	283	445	16.0
