255322CY-3 Industrial Air Spring Triple Convolutions With Stamped Flange and Plate

255322CY-3 Industrial Air Spring Triple Convolutions With Stamped Flange and Plate

  • 255322CY-3 Industrial Air Spring Triple Convolutions With Stamped Flange and Plate
  • 255322CY-3 Industrial Air Spring Triple Convolutions With Stamped Flange and Plate
  • 255322CY-3 Industrial Air Spring Triple Convolutions With Stamped Flange and Plate
  • 255322CY-3 Industrial Air Spring Triple Convolutions With Stamped Flange and Plate
  • 255322CY-3 Industrial Air Spring Triple Convolutions With Stamped Flange and Plate
255322CY-3 Industrial Air Spring Triple Convolutions With Stamped Flange and Plate
Product Details:
Place of Origin: China
Brand Name: GUOMAT
Certification: ISO/TS16949:2009
Model Number: 255322CY-3
Payment & Shipping Terms:
Minimum Order Quantity: 1pc
Packaging Details: strong carton box or as customers need
Delivery Time: 2-8 work days
Payment Terms: T/T, Western Union,Paypal or Others
Supply Ability: 1000pcs/week
Contact Now
Detailed Product Description
Material: Rubber And Steel GUOMAT: 255322CY-3
Warranty: 12 Months Net Weight: 7.30 KG
Other Name: Air Spring Pressure Ability: 0.2-0.8 M Pa
Gross Weight: 8.50 KG Flange Ring: With
Connection Method: Stamped Flange Connection
High Light:

Triple Convolutions Industrial Air Spring

,

255322CY-3 firestone air ride suspension

,

255322CY-3 air spring suspension system

255322CY-3 Industrial Air Spring Triple Convolutions With Stamped Flange and Plate





Weight and packing of 255322CY-3:



Net Weight:7.3 KG



Gross Weight:8.5 KG



Package Size:270mm*270mm*270mm



Compressed height:118mm

Maximum Height:400mm

Full stroke:282mm

Working medium:water, air

Working pressure:< 0.7Mpa

Burst pressure:> 1.6Mpa

Endurance cycle:> 10"

Temperature:-35℃ ~+60℃





Rubber Bellows

In 0.7 M pa,Rubber Bellows Diameter : 270mm

Rubber Bellows Natural Height :245 mm



Bumper block / Buffer block

Without Bumper Block



Girdle Hoop / Girdle Ring

With 2 Girdle Hoop





OEM Original Equipment Manufacturer:



 Manufacturer:                                          Complete Numbers

Airkraft: 115056
Contitech: FT 210-32
Dunlop: SP1539(10X3)
Weforma: WBD-G450
Stroke: 230mm
Condition: New




Bellows Type Ø Max Min. Height Max. Height Total Stroke Static Height Ø Pitch Circle* Ø Space Envelope Weight in kg

Single layer



41⁄2 x 1 125 45 90 45 65 93 140 0.75
6x1 162 50 110 60 80 127 180 1.69

Double layer



23⁄4 x 2 78 65 115 50 92 64 95 0.26
41⁄2 x 2 125 65 145 80 100 93 140 0.93
6x2 168 75 215 140 140 127 180 2.08
211⁄2 x 2 570 90 390 300 200 N/A 595 21.0
Triple layer 23⁄4 x 3 78 80 145 65 119 64 95 0.57
41⁄2 x 3 125 100 200 100 145 93 140 1.15
6x3 168 109 262 153 187 127 180 2.47







The Composition Of Industrial Convoluted Air Spring Element Has The Following Aspects





Nut / Blind Nut – As well a permanent part of the Cover Plate assembly. Provides an alternative to bolt installation system. It is inside defect within the iron plate



Gas Hole / Air inlet / Air Fitting – Most usually 1/4 N.P.T. which provides the air entrance to the rubber bellows.



Cover Plate - Curled up to more durable bellows design and the largest quality control in the factory. Allows 100% of the leak test before shipment.



Rubber Bellows - Air Bellows includes four layers of materials: an inner layer, two layer cord - reinforced fabrics, and a cover. Construction of a natural rubber provides – 65F functional properties.



Bumper block / Buffer block - Solid rubber or engineering plastic device designed to prevent major damage to the vehicle or suspension in the event of a sudden loss of air pressure in the spring.



Girdle Hoop / Girdle Ring - Molded wire-wound ring to provide lateral stability of the complex type spring bellows.
