12''X2 Series Dunlop Air Spring SP1541 Double Convoluted Flange Air Lift Bag With 4 Screws
Product Description
Manufacturer: DUNLOP
Manufacturer Part Number: SP1541
Manufacturer Part Number: SP 1541
Manufacturer Part Number: 12''X2
Manufacturer Part Number: 12X2
Firestone Part Number: W01-R58-4061
Firestone Part Number: W01 R58 4061
Firestone Part Number: W01R584061
Firestone Part Number: WO1-R58-4061
Firestone Part Number: WO1 R58 4061
Firestone Part Number: WO1R584061
Contitech Part Number: FD412-22
Contitech Part Number: FD 412-22
Contitech Part Number: FD412-22 DS
Contitech Part Number: FD 412-22 DS
Norgren Part Number: M/31122
Norgren Part Number: M 31122
Norgren Part Number: M31122
Parker Part Number: 9109041
12''X2 Air Spring Technical Data
Cover Plate Diameter:Ø260mm
Air Inlet: G1/2 ; 1/2BSP
Center Distance Between Screws: Ø231.8±0.2
Rubber Bellows MAX Diameter(8 bar): Ø330mm
Space Required: Ø345mm
Cover Thickness: 15.5mm
Screw: M10X1.5
Screw Length: 27.3mm
Natural Height: 165mm
Max.Height: 300mm
Min.Height: 75mm
Other Related Dunlop Air Spring
|
DUNLOP Pneuride
|
DUNLOP Springride
|
DUNLOP Pneuride
|
DUNLOP Springride
|
|
4 1/2 X 1
|
SP2334
|
4 1/2 X 2
|
SP2441
|
|
4 1/2 X 3
|
SP2895
|
6''X1(AI)
|
SP2913
|
|
6''X1(Steel)
|
SP1536
|
6''X2(AI)
|
SP2917
|
|
6''X2(Steel)
|
SP1482
|
6''X3(AI)
|
SP2923
|
|
6''X3(Steel)
|
SP2861
|
8''X1
|
SP1537
|
|
8''X2
|
SP1490
|
8''X3
|
SP2863
|
|
10''X1
|
SP2523
|
10''X2
|
SP1538
|
|
10''X3
|
SP1539
|
12''X1
|
SP1540
|
|
12''X2
|
SP1541
|
12''X3
|
SP1542
|
|
14'' 1/2 X1
|
SP1543
|
14'' 1/2 X2
|
SP1556
|
|
14'' 1/2 X3
|
SP1558
|
16''X2
|
SP1557
|
|
16''X3
|
SP2141
|
21'' 1/2 X 2
|
SP1408
|
|
26''X2
|
SP2342
|
|
|
Advantages of Air Springs Applied to Conveyor Belts
- Improved product protection: Air springs can help cushion products and reduce impact when they are conveyed, ensuring that the products arrive at their destination undamaged.
- Reduced noise and vibration: Air springs can absorb vibrations and reduce noise levels, making the conveyor system more pleasant to work with and reducing wear and tear on other components.
- Longer lifespan: As air springs help to reduce shock and vibration, they can help components of the conveyor system last longer and require less maintenance.
- Improved safety: By reducing shock and vibration, air springs can help reduce the likelihood of accidents or injuries, making the workplace safer for employees.
- Energy efficiency: Air springs can reduce the energy required to operate the conveyor system by absorbing and releasing energy during operation, allowing for more efficient use of energy.
The Real Pictures of Dunlop Air Spring
