Goodyear 1B8-550 Single Cnvoluted Type Air Spring For Equipment Air Spring

Product Details:

Place of Origin:	Guangzhou,China
Brand Name:	GUOMAT
Certification:	ISO/TS16949:2009
Model Number:	1B8X4

Payment & Shipping Terms:

Minimum Order Quantity:	5pcs
Price:	USD49.9-59.9/PC
Packaging Details:	Strong Carton Box or as Customers Requirement
Delivery Time:	3-7 Working Days
Payment Terms:	L/C, T/T, Western Union Or Others
Supply Ability:	1000PCS/Week

Contact Now

Detailed Product Description

Condition:	Brand-New	Sample:	Available
Function:	Reduce Shock	Transport Package:	Cartons
Part:	Air Spring	Type:	Gas-Filled
Goodyear:	1B8-550	Contitech:	FS120-10
Highlight:	Single Cnvoluted Type Air Spring , 1B8-550 Air Spring , Equipment Air Spring

Goodyear 1B8-550 Single Cnvoluted Type Air Spring For Equipment Air Spring

Part Number	1B8X4
Working Temperature	-40°C bis +70°C
OEM NO.	W01-358-7564/1B8-550/FS120-10
Failure testing	≥3 millions
Main product we sell	Air Spring,Convoluted Air Spring,Industrial Air Springs,Air Suspension Spring,Air Compressor,Air Valve,Bus Rubber Bellows,Truck & Trailer Air Bags,Cabin Air Shock,Electric Water Pump

Cross Reference

Firestone W01-358-7564 / W01 358 7564 / W013587564

Goodyear 1B8-550 / 1B 8-550

Contitech FS120-10 / FS 120-10

Air bag is a rubber and fabric bladder that holds air pressure to support a loat and isolate passengers and cargo from the shock of motion caused by road irregularities.

As the air pressure increases,the air spring can support more loat while the spring rate increases.The larger the air spring,the greater the maximum load it can support.

1B8X4 Industrlal Air Replacement Parts Technical Data

Top Cover Plate Diameter:135mm
Bottom Cover Plate Diameter:135mm
Screw Center Distance of Top Cover Plate:70mm
Screw Center Distance of Bottom Cover Plate:70mm
Air Hole/Air Inlet/Gas hole:1/4 NPTF
Top Cover Plate Screw (Nut) Tooth:2X3/8-16UNC
Bottom Cover Plate Screw(Nut) Tooth:2X3/8-16UNC
Rubber Bellows MAX.Diameter:MAX.230
The Working Stroke:50mm~140mm

Applications

Industrial actuator
Vibration isolator
Press machines
Conveyors
Lifts
Packaging machines

Features

Fabric-reinforced rubber
Flexible media
Provides linear and angular motion
Reduces harmful effects of vibration

Goodyear 1B8-550 Single Cnvoluted Type Air Spring For Equipment Air Spring 0

1. Q: How to order ?
A: Step 1, please tell us what model and quantity you need;
Step 2,then we will make a PI for you to confirm the order details;
Step 3,when we confirmed everything ,you can arrange the payment;
Step 4,finally we deliver the goods within the stipulated time.

2. Q: When will make delivery ?
A: Delivery time is 2-8woring days.

3. After-sales service
1 year warranty for all kinds of products;
If you have any questions after receiving the goods,please feel free to contact me,as an experienced manufacturer ,you can rest assured of the quality and after-sales service.

4. Payment
T/T,Western Union,L/C

5. Transportation
Transportation by DHL,UPS,EMS,Fedex,Air freight,Sea freight.
