Norgren M/31081 Air Suspension Spring Cross Firestone W013584054 Air Actuator

Product Details:

Place of Origin:	Guangdong, China
Brand Name:	GUOMAT
Certification:	ISO/TS16949, ISO9001
Model Number:	1B8×1T

Payment & Shipping Terms:

Minimum Order Quantity:	5
Price:	Negotiable
Packaging Details:	Strong Carton Box or as Customers Requirement
Delivery Time:	5-8 Working Days
Payment Terms:	L/C, D/A, D/P, Western Union
Supply Ability:	1000PCS/Week

Contact Now

Detailed Product Description

Model NO.:	1B8×1T	Spring Material:	Rubber And Steel
Air Spring Type:	Single Convoluted	Function:	Reduce Shock
DUNLOP:	8''×1	Sample:	Available
Type:	Gas-Filled	Ship To:	Worldwide
Highlight:	Norgren M/31081 Air Suspension Spring , W013584054 Air Suspension Spring , W013584054 Air Suspension Spring

Norgren M/31081 Air Suspension Spring Cross Firestone W013584054 Air Actuator

Product Information

Maximum Diameter	230 mm
Space Required	240 mm
Minimum Height	47 mm
Maximum Height	120 mm
Total Stroke	73 mm
Static Height	90 mm
Effective Area at Stactic Height	200 cm²
Bellows Weight	3.05 kg

Alternative Items

Fire stone Number W01R584054
Fire stone Number W01 R58 4054
Fire stone Number W01-R58-4054
Fire stone Bellows Number 4054
Fire stone Bellows Number WO1R584054
Fire stone Bellows Number WO1 R58 4054
Fire stone Bellows Number WO1-R58-4054
Dunlop Number 8" x 1 ; 8x1 ; 8X1
Dunlop Number SP1537
Dunlop Number SP 1537
Dunlop Number sp1537
Dunlop Number sp 1537
Contitech Number FS 138-8 DS
Contitech Number FS138-8 DS
Contitech Bellows Number FS138-8DS
Norgren Number M/31081
Norgren Number M31081
Norgren Number M 31081
Parker Number 9109014

Precautions to Observe

Do not exceed stated stroke.
Do not inflate assembly when it is unrestricted.
Do not inflate beyond pressures stated without
prior consultation with Dunlop.
Respect maximum and minimum heights.
The bellows must be securely fixed.
Do not use without air pressure.

Air Spring Advantages

The industrial air spring widely used in paper-making machinery, vehicle detection equipment, mechanical gripper, shaking table ect. to effectively improve the working efficiency, safety and service life of the equipment. In these fields, the products plays an important role of damping, lifting, supporting, and so on. It helps customers to save manufacturing costs and win more economic profits.

The products features low cost, wide use and easy operation.
It achieves long service life, and requires no maintenance and lubrication.
This product allows for flexible expansion and contraction, strong loading capacity, convenient design, and simple structure.
It comes with no friction and soft medium.

Company Profile

Guangzhou Guomat Air Spring Co., Ltd. is founded in 2008, the company covers an area of 20000 square meters, registered capital is 10 million yuan, the existing various types of professional and technical personnel is 85 people.The company is located in Guangzhou, about 15min's drive from Baiyun Airport. and our main products are air spring, rubber bellows, air suspension spring, air suspension compressor and refitted suspension system. They are widely used in bus, truck, cabin, vehicles' seat, luxurious car and industrial machine field.

The Real Photo

FAQ

1. Are you a Manufacture factory?
Yes, We are the direct manufacture factory, located in Guangzhou China, Which is specialized in air spring in China for over 15years experience from 2008 years.

2. What is your main products?
Our main products are air spring, rubber bellows, air suspension spring, air suspension compressor and refitted suspension system.

3. Is the sample available?
Yes, Usually we send the samples by TNT,DHL,FEDEX or UPS.

4. What is your warranty term?
There is a 12months warranty for our export products has run out from the date of the shipment.

5. Can i use my own logo and design on products?
YES,OEM is welcomed.

6. I can not find out the items what i want from your website, can you offer the products i need?
YES.One of our service term is sourcing the products that our customers need,So please tell us the details information of the item.
