New Style Rubber Air Spring Air Suspension W01-358-6927/FD200-25453/ 2B9-218

Product Details:

Place of Origin:	Guangzhou,China
Brand Name:	GUOMAT
Certification:	ISO/TS16949:2009
Model Number:	2B6927

Payment & Shipping Terms:

Minimum Order Quantity:	5pcs
Price:	USD59.9-69.9/PC
Packaging Details:	Strong Carton Box or as Customers Requirement
Delivery Time:	3-7 Working Days
Payment Terms:	L/C, T/T, Western Union Or Others
Supply Ability:	1000PCS/Week

Contact Now

Detailed Product Description

Name:	Crimped Convoluted Air Springs	Condition:	Brand-New
Function:	Reduce Shock	Quality:	100% Tested
Warranty:	1 Year	Firestone:	W01-358-6927
Goodyear:	2B9-218	Contitech:	FD 200-25 453
Highlight:	W01-358-6927 Rubber Air Spring , FD200-25453 Rubber Air Spring

New Style Rubber Air Spring Air Suspension W01-358-6927/FD200-25453/ 2B9-218

Item	Value
OEM.NO.	W01-358-6927
Type	Air Spring
Warranty	12 Months
Truck Model	Heavy Duty Truck
Color	Black
Place of Origin	Guangzhou,China
Certification	ISO/TS16949:2009
Material	Rubber+Steel
Packing	Neutral Packing
MOQ	1 Pcs
Quality	High-Quality
Position	Auto/Truck parts
Application	Auto Suspension Systems

Cross Number

Firestone

Firestone Style 20-2

W01-358-6927 / WO1-358-6927

W01 358 6927 / WO1 358 6927

W013586927 / WO13586927

Contitech

FD 200-25 453

FD200-25 453

FD200-25453

161336

Goodyear

2B9-218

2B9 218

2B9218

578923206

578 92 3 206

578-92-3-206

578923202

578 92 3 202

578-92-3-202

Triangle

6332/4453

AS-4453

FleetPride

AS6927

Taurus

Automann

SP2B12RA-6927

Original Number

Reyco

12906-01

Leland

Sc2072

SAF Holland

57006927

Tuthill Technology

1290601

Loadguard

SC2072

Navistar/Fleetrite

1685176C1

Taurus

AS218-6927

Technical Details

Top Cover Plate Diameter:160mm

Bottom Cover Plate Diameter:160mm

Gas Hole / Air inlet:1/4NPT

Rubber Bellows MAX Diameter:262mm

The Working Stroke:MAX 325 mm to MIN 81 mm

Top Cover Plate Screw (Nut) Tooth With Air Inlet:3/4-16UNF

Bottom Cover Plate Screw (Nut) Tooth:2X3/8-16UNC

Screw Center Distance of Bottom Cover Plate:89mm

Weight: 6.9Ib

1/4-18 NPTF: max.22 lbf ft

3/4-16 UNF: max. 50 lbf ft

3/8-16UNC: max. 20 lbf ft

How to Install Air Springs For Large Dryers

Preparation: Make sure you have the correct tools and equipment, and read and understand the relevant installation instructions and operating manuals before installation.
Determine the installation location: Choose an appropriate location to install the air spring. Make sure the location has enough space and can withstand the weight and vibration of the dryer.
Install the bracket: Install the bracket to support the weight of the dryer according to the design and installation requirements of the dryer. Make sure the bracket is firm and reliable and can withstand the load of the dryer.
Install the air spring: According to the installation instructions of the dryer, properly install the air spring on the bracket. Make sure the air spring is firmly connected to the dryer and can provide proper support and cushioning.
Connect the air source: Connect the air source to the air spring. Make sure the connection is correct and the air source can provide enough air pressure to support the weight of the dryer.
Test and adjust: After the installation is completed, test to ensure that the air spring is working properly and can provide proper support. Make adjustments as needed to ensure the balance and stability of the dryer.

New Style Rubber Air Spring Air Suspension W01-358-6927/FD200-25453/ 2B9-218 0

1. Q: How to order ?

A: Step 1, please tell us what model and quantity you need;

Step 2,then we will make a PI for you to confirm the order details;

Step 3,when we confirmed everything ,you can arrange the payment;

Step 4,finally we deliver the goods within the stipulated time.

2. Q: When will make delivery ?

A: Delivery time is 2-8woring days.

3. After-sales service

1 year warranty for all kinds of products;

If you have any questions after receiving the goods,please feel free to contact me,as an experienced manufacturer ,you can rest assured of the quality and after-sales service.

4. Payment

T/T,Western Union,L/C

5. Transportation

Transportation by DHL,UPS,EMS,Fedex,Air freight,Sea freight.
