Contitech Air Spring FT330-29 432 Goodyear 3B12-301 Industrial Air Springs 578933100

Contitech Air Spring FT330-29 432 Goodyear 3B12-301 Industrial Air Springs 578933100

  • Contitech Air Spring FT330-29 432 Goodyear 3B12-301 Industrial Air Springs 578933100
  • Contitech Air Spring FT330-29 432 Goodyear 3B12-301 Industrial Air Springs 578933100
  • Contitech Air Spring FT330-29 432 Goodyear 3B12-301 Industrial Air Springs 578933100
  • Contitech Air Spring FT330-29 432 Goodyear 3B12-301 Industrial Air Springs 578933100
  • Contitech Air Spring FT330-29 432 Goodyear 3B12-301 Industrial Air Springs 578933100
  • Contitech Air Spring FT330-29 432 Goodyear 3B12-301 Industrial Air Springs 578933100
Contitech Air Spring FT330-29 432 Goodyear 3B12-301 Industrial Air Springs 578933100
Product Details:
Place of Origin: Guangzhou,China
Brand Name: GUOMAT
Certification: ISO/TS16949:2009
Model Number: 3B8010
Payment & Shipping Terms:
Minimum Order Quantity: 5pcs
Price: USD79.9-99.9/PC
Packaging Details: Strong Carton Box or as Customers Requirement
Delivery Time: 3-7 Working Days
Payment Terms: L/C, T/T, Western Union Or Others
Supply Ability: 1000PCS/Week
Contact Now
Detailed Product Description
Type: Industrial Air Spring N.W.: 7.5 Kg
Pressure Ability: 0.2-0.8 M PA Plate Diameter: 231 Mm
Air Inlet: 1/4nptf Top Plate Hole/Stud: 2X3/8-16unc
Top Plate Dia: 231 Mm Trademark: Neutral
Highlight:

Goodyear 3B12-301 Industrial Air Springs

,

Industrial Air Springs 578933100

Contitech Air Spring FT330-29 432 Goodyear 3B12-301 Industrial Air Springs 578933100



CONTITECH FT 330-29 Cross others OEM



BELLOW Numbers COMPLETE NO. COMPLETE Numbers
AIRKRAFT 116008 AIRKRAFT 115033 AIRKRAFT 115027
Fire stone Air Spring FLEX 38R/38D CONTITECH FT 330-29 773 CONTITECH FT 330-29 430
Fire stone Air Spring 095.0047 Fire stone Air Spring W01-358-8013 FT 330-29 498
GOODYEAR FLEX 556 3 3 8334 GOODYEAR 3B12-305 FT 330-29 503
578 93 3 100 AIRKRAFT 115035 FT 330-29 702

 		 CONTITECH FT 330-29 432 Fire stone Air Spring W01 358 8006

 		 Fire stone Air Spring W01-358-8010 W01 358 8030

 		 GOODYEAR 3B12-301 GOODYEAR 3B12-304


3B8010 Technical Parameters



Nut / Blind Nut



Top Cover Plate Screw (Nut) Tooth : 2pcsX3/8-16UNC

Top Cover Plate Screw (Nut) Tooth : 2pcsX3/8-16UNC

Screw Center Distance of Top Cover Plate : 157.5mm

Bottom Cover Plate Screw (Nut) Tooth : 2pcsX3/8-16UNC

Screw Center Distance of Bottom Cover Plate : 157.5mm



 Gas Hole / Air inlet / Air Fitting

Gas Hole / Air inlet : 1/4 N P.T.F. / 1/4NPTF



 Cover Plate

Top Cover Plate Diameter: 231 mm

Bottom Cover Plate Diameter: 231 mm



Rubber Bellows

Rubber Bellows MAX Diameter: 330 mm

Rubber Bellows Natural Diameter :300 mm

The Working Stroke : MAX 460 mm to MIN 130 mm

Maximum Height : 460 mm

Minimum Height :130 mm

Compression Height : 330 mm



 Bumper block / Buffer block

Without Bumper Block



 Girdle Hoop / Girdle Ring

With Girdle Hoop :Two Pieces of Girdle Hoop



Contitech Air Spring FT330-29 432 Goodyear 3b12-301 Industrial Air Springs 578933100

Contitech Air Spring FT330-29 432 Goodyear 3b12-301 Industrial Air Springs 578933100
Contitech Air Spring FT330-29 432 Goodyear 3b12-301 Industrial Air Springs 578933100
