1B12-313 Original Goodyear Rubber Air Balloon Spring For Drying Industrial

Product Details:

Place of Origin:	Mexico
Brand Name:	Goodyear
Certification:	ISO/TS16949:2009
Model Number:	1B12-313

Payment & Shipping Terms:

Minimum Order Quantity:	5pcs
Price:	USD99.9-199.9/PC
Packaging Details:	Strong Carton Box or as Customers Requirement
Delivery Time:	3-7 Working Days
Payment Terms:	L/C, T/T, Western Union Or Others
Supply Ability:	1000PCS/Week

Contact Now

Detailed Product Description

Brand:	Goodyear	Function:	Reduce Shock
Quality:	100% Tested	OEM:	578-91-3-301
Transport Package:	Cartons	After-sales Service:	1 Year
Part:	Air Spring	Position:	Industrial Machine
Highlight:	Goodyear Rubber Air Balloon Spring , 1B12-313 Rubber Air Balloon Spring

1B12-313 Original Goodyear Rubber Air Balloon Spring For Drying Industrial

Product Details

Manufacturer: Goodyear
Manufacturer P/N: 1B12-313
Manufactured in: Mexico
Manufacturer Flexmember: 578-91-3-301

OEM Contitech FS330-11 474
OEM Contitech FS 330-11 474
OEM Contitech 64596
OEM Contitech 6-4-5-9-6
OEM Firestone W01-358-7008

OEM Manfacturer	OEM Number
Goodyear	1B12-313
Goodyear	1B 12-313
Goodyear	1B12 313
Goodyear	1B 12 313
Goodyear	578-91-3-301
Goodyear	578913301
Goodyear	578 91 3 301
Contitech	FS 330-11 474
Firestone	W01-358-7008
Firestone	W013587008
Firestone	W01 358 7008
Firestone	WO1-358-7008
Firestone	WO1 358 7008
Firestone	WO13587008

Bellow Type: Single
Bottom Plate/Pison Type:
Top Plate Hole/Stud Qty: 3
Top Plate Dia: 9
Top Plate C to C Diameter: 6.2
Bottom Plate Hole Stud Qyt: 2
Bottom Plate Dia: 9
Bottom Plate C to C Diameter: 6.2
Bottom Plate Part #:
Bottom Plate Alignment: Parallel
Bumper: No
Bracket:
Min Height: 2.3
Max Height: 7.2

Air Spring for Dryer
Air springs are suitable for large dryers. Durable, sophisticated and cost-effective, these air springs can be used in a variety of drive and vibration isolation applications, including dryers.

Air Spring Introduction

Air springs have been used in heavy duty vehicle suspension systems for nearly a century, where they have been able to provide usefulness by taking advantage of the compressed air required for vehicle braking systems. Air springs have provided a two-fold advantage over mechanical leaf- or coil-springs. One advantage with air suspension is the extra comfort provided by being able to vary the air pressure inside the spring, which changes the spring rate, and therefore, ride quality. Additionally, because variable control over air pressure adjusts the deck or trailer height, aligning loading docks to the level of the deck is possible when dock plates are unavailable.
