3B15-375 Goodyear Triple Convoluted Rubber Bellow 578-93-3-377 Without Bumper

Product Details:

Place of Origin:	Guangdong, China
Brand Name:	GUOMAT
Certification:	ISO/TS16949, ISO9001
Model Number:	3B15-375

Payment & Shipping Terms:

Minimum Order Quantity:	5
Price:	Negotiable
Packaging Details:	Strong Carton Box or as Customers Requirement
Delivery Time:	5-8 Working Days
Payment Terms:	L/C, D/A, D/P, Western Union
Supply Ability:	1000PCS/Week

Contact Now

Detailed Product Description

Model Number:	3B15-375	Structure:	Triple Convoluted
Brand:	GUOMAT	Quality:	100% Tested
OEM NO.:	W01-358-7808	Minimum Height:	4.7 Inches
Maximum Height:	17.0 Inches	Sample:	Available
Highlight:	Goodyear Triple Convoluted Rubber Bellow 5 , 3B15-375 Triple Convoluted Rubber Bellow , Triple Convoluted Rubber Bellow Without Bumper

3B15-375 Goodyear Triple Convoluted Rubber Bellow 578-93-3-377 Without Bumper

Product Specification

Air Connection	1/4'' or 3/4''
Screw Type	3/8''-16UNC
C to C Diameter	6.25 Inches
Body Max. Diameter	16.5 Inches
Cover Plate Width	11.3 Inches
Max Extended Height	17 Inches
Min Compressed Height	4.7 Inches
Bellow Type	Triple Convoluted
Stud / Hole on Top Plate	4
Stud / Hole on Bottom Plate	3

Goodyear Other Type Air Springs

Assembly Number

Elastomer

Air Fitting

Bumper Included

3B15-375

3B15-376

3B15-377

3B15-378

578933377

FLEXMEMBER ONLY

NAT. RUBBER

1/4''-18 BPTF OFFSET 3.125''

3/4''-14 BPTF OFFSET 3.125''

Part Numbers

Goodyear 3B15-375
Goodyear 3B 15-375
Goodyear 3B15 375
Goodyear 578933377
Goodyear 578-93-3-377
Goodyear 578 93 3 377
Fire-stone W013587808
Fire-stone W01 358 7808
Fire-stone W01-358-7808
Fire-stone WO13587808
Fire-stone WO1 358 7808
Fire-stone WO1-358-7808
Contitech FT 530-32 CI 1/4 NPT
Contitech FT 530 32 CI 1/4 NPT
Contitech FT530-32 CI 1/4 NPT
Enidine YI-3B15-375
Enidine YI-3B15 375
Enidine YI-3B15375

We Can Offer Goodyear Other Type Air Springs

Part No.	Usable Stroke	Max Dia. @ 100 psi In	Min Height Inches	Max Height Inches	Bumper	Force At Actuator Height Limit (Pounds)				Force At Compressed Height Limit (Pounds)
Part No.	Usable Stroke	Max Dia. @ 100 psi In	Min Height Inches	Max Height Inches	Bumper	100 psi	80 psi	60 psi	40 psi	100 psi	80 psi	60 psi	40 psi
3B12-305	13.3	13	4.7	18	NO	29.25	2165	1370	735	10165	7915	5855	3960
3B14-351	10.9	15.5	7.3	18.2	YES	4770	3385	1935	940	13885	10550	7810	5220
3B14-353	10.9	15.5	7.3	18.2	NO	4770	3385	1935	940	13885	10550	7810	5220
3B14-354	13.5	15.5	4.7	18.2	NO	4770	3385	1935	940	15200	11080	8240	5220
3B14-361	13.5	15.5	4.7	18.2	NO	4770	3385	1935	940	15200	11080	8240	5220
3B15-375	12.3	16.5	4.7	17.0	NO	6165	4775	3470	2225	16650	13275	9765	6555
3B15-376	9.7	16.5	7.3	17.0	YES	6165	4775	3470	2225	14925	11865	8905	5945
3B15-377	12.3	16.5	4.7	17.0	NO	6165	4775	3470	2225	16650	13275	9765	6555
3B15-378	9.7	16.5	7.3	17.0	YES	6165	4775	3470	2225	14925	11865	8905	5945

Company Profile

Guangzhou Guomat Air Spring Co., Ltd. is founded in 2008, the company covers an area of 20000 square meters, registered capital is 10 million yuan, the existing various types of professional and technical personnel is 85 people.The company is located in Guangzhou, about 15min's drive from Baiyun Airport. and our main products are air spring, rubber bellows, air suspension spring, air suspension compressor and refitted suspension system. They are widely used in bus, truck, cabin, vehicles' seat, luxurious car and industrial machine field.

Product Images

FAQ

1. Are you a Manufacture factory?
Yes, We are the direct manufacture factory, located in Guangzhou China, Which is specialized in air spring in China for over 15years experience from 2008 years.

2. What is your main products?
Our main products are air spring, rubber bellows, air suspension spring, air suspension compressor and refitted suspension system.

3. Is the sample available?
Yes, Usually we send the samples by TNT,DHL,FEDEX or UPS.

4. What is your warranty term?
There is a 12months warranty for our export products has run out from the date of the shipment.

5. Can i use my own logo and design on products?
YES,OEM is welcomed.

6. I can not find out the items what i want from your website, can you offer the products i need?
YES.One of our service term is sourcing the products that our customers need,So please tell us the details information of the item.
