12" x 3 Original Norgren M/31123 Single Acting Air Bellow 330mm Stroke Industrial Air Spring

Product Details:

Place of Origin:	Guangzhou China
Brand Name:	Norgren
Certification:	ISO/TS16949, ISO9001
Model Number:	M/31123

Payment & Shipping Terms:

Minimum Order Quantity:	5pcs
Price:	USD199.9-299.9/PC
Packaging Details:	Strong Carton Box or as Customers Requirement
Delivery Time:	3-7 Working Days
Payment Terms:	L/C, T/T, Western Union Or Others
Supply Ability:	1000PCS/Week

Contact Now

Detailed Product Description

Part:	Industrial Air Spring	Stroke Length:	330 Mm
Transport Package:	Cartons	After-sales Service:	1 Year
Medium:	Compressed Air	Port Size:	G1/2
OEM No.:	M/31123	Operating Temperature:	-40 ... 70 °C, -40 ... 158 °F
Highlight:	330mm Stroke Industrial Air Spring , Single Acting Industrial Air Spring , Norgren M/31123 Industrial Air Spring

12" x 3 Original Norgren M/31123 Single Acting Air Bellow 330mm Stroke Industrial Air Spring

Product Description

Product Name: Norgren Air Spring

Brand: NORGREN

Model NO.: M/31123 / M 31123 / M31123

NominalØ(inch)xconvolutions: 12''x2 / 12'' x 2 / 12x2

Medium Compressed Air

Operating Temperature: -40 ... 70 °C, -40 ... 158 °F

Operating Pressure: 0 ... 8 bar

Port Size: G1/2

Nominal Diameter: 12"

Number Of Convolutions: 3

Replaces These Air Springs (Air Bellows)
Firestone No.: W01-R58-4062 / W01R584062 / W01 R58 4062

Firestone Style: 12''x2 / 12'' x 2 / 12x2

Dunlop FR: 12''x2 SP1542

Continental ContiTech: FT 412-32 DS CR 66339

Continental ContiTech: FT 412-32 1/2 M10

Continental ContiTech: FT 412-32 DS G1/2

Continental ContiTech: FT 412-32 DS G1/2 CR

Continental ContiTech: FT 412-32 DS CR G1/2

Continental ContiTech Bellows:: FT 412-32 / FT412-32 / FT41232

Parker: 12''X3 9109051

M/31123 Norgren Air Spring Technical Data

Weight	6.9KG
Maximum height	430mm
Minimum compression height	100mm
Diameter of cover plate	260mm
Pore size	G1/2
Screw size	M10
Center distance between screws	232mm
Maximum outer diameter of bellows	325mm
Required installation space	350mm

Force F (kN)

Pressure P	bar	3	4	5	6	7	8	Volume(l)
Height H (mm)	350	9.8	13.2	16.7	20.5	24.3	28.4	17.2
	300	12.3	16.5	20.8	25.3	29.9	34.7	15.3
	250	14.4	19.3	24.2	29.4	34.5	39.9	12.9
	200	16.4	22.0	27.7	33.5	39.4	45.6	10.0
	150	18.8	25.1	31.4	37.8	44.2	50.7	7.2

Norgren industrial air spring is a pneumatic component for various applications, which is mainly used to provide smooth support and shock absorption effects. This air spring is usually used for industrial equipment, cars and other occasions that need to be shock -absorbing and supported.

Main Features:
Safety: Air spring design is used for safety operations, which can effectively absorb impact and vibration.
Multifunction: Suitable for a variety of application scenarios, including car interior and industrial machinery.
Duravity: It usually has a long service life and can work under extreme conditions.
