FD120-17 Contitech Rubber Air Suspension 2B-181 Airkraft Convoluted Industrial Air Bellows

Product Details:

Place of Origin:	GuangDong, China
Brand Name:	GUOMAT
Certification:	ISO/TS16949:2009
Model Number:	2B120-17

Payment & Shipping Terms:

Minimum Order Quantity:	6PCS
Price:	$59.9-69.9/pc
Packaging Details:	Strong Carton Box Or As Customers Need
Delivery Time:	2-8 work days
Payment Terms:	L/C, T/T, Western Union
Supply Ability:	1000pcs/week

Contact Now

Detailed Product Description

Model Name:	Double Convoluted Air Help Suspension Spring	Warranty:	1 Year
Screw Tooth:	M8	Other Name:	Convoluted Style Airbag,Bellows Type Air Suspension Spring
Contitech:	FD120-17	Material:	Rubber And Steel
Airkraft:	2B-181	Air Hole:	G3/4
Highlight:	Contitech rubber air suspension bellow , Industrial air spring with warranty , Convoluted air bellow for machinery

FD120-17 Contitech Rubber Air Suspension 2B-181 Airkraft Convoluted Industrial Air Bellows

Product Overview

Item Type: Air Spring/Shock Absorber Spring/Air Bellows

Brand: GUOMAT

Model Number: 2B120-17

Material: Rubber And Steel

Warranty: 1 Year

MOQ: 1 PCS If We Have Stock

Delivery Time: 2-8 Working Days

Payment Methods: T/T, L/C, PayPal, Western Union

Compatible Part Numbers

Continental ContiTech: FD 120-17 Cl G3/4

Continental ContiTech: FD 120-17 C G3/4 M8

Continental ContiTech: FD 120-17 3/4 M8

Continental ContiTech: FD 120-17 C12682030 000

Continental ContiTech Bellow: FD 120-17/FD 120 17/FD12017

Goodyear: 2B8-2152/2B8 2152/2B82152

Goodyear Flex No: 578-92-3-2151/578 92 3 2151/5789232151

Festo: EB-215-155/EB 215 155/EB215155

Dunlop FR: 8"x2 S08201

Norgren: PM/31082/PM31082/PM31082

Nominal 0 (inch) x convolutions: 8" x2/8"x2/8x2

Technical Specifications

Top Cover Plate Diameter	135mm
Bottom Cover Plate Diameter	135mm
Air Inlet/Gas Hole	G3/4
Top Cover Plate Screw (Nut) Tooth	2XM8X1.25
Bottom Cover Plate Screw (Nut) Tooth	2XM10X1.5
Screw Center Distance Of Top Cover Plate	70mm
Screw Center Distance Of Bottom Cover Plate	70mm
Rubber Bellow MAX Diameter	215mm max.OD
The Working Stroke	MAX 230mm to MIN 75mm
Maximum Height	230mm
Minimum Height	75mm
Compression Height	155mm

Why Choose GUOMAT?

Professional Air Spring Manufacturer - GUOMAT specializes in air springs and air suspension components with solid industry experience, supporting both OEM projects and aftermarket applications.

Consistent Quality Control - We implement stable quality control throughout production, from raw material selection to final inspection, ensuring reliable performance and durability.

Reliable Supply Capability - With an established production base and experienced technical team, we maintain stable output and flexible production capacity.

Cost-Effective Solutions - By optimizing manufacturing processes, we deliver competitive pricing while maintaining dependable product quality.

OEM Replacement & Aftermarket Support - Our products meet OEM replacement standards and offer compatibility with major international brands and flexible customization options.

Product Images
