3B12-304 Original Goodyear Triple Bellow Air Spring FT 330-29 430 Contitech Air Lift Bags

Product Details:

Place of Origin:	GuangDong, China
Brand Name:	Goodyear
Certification:	ISO/TS16949:2009
Model Number:	3B12-304

Payment & Shipping Terms:

Minimum Order Quantity:	6pcs
Price:	$199.9-299.9/pc
Packaging Details:	Strong Carton Box Or As Customers Need
Delivery Time:	2-8 work days
Payment Terms:	T/T,Western Union,L/C
Supply Ability:	1000pcs/week

Contact Now

Detailed Product Description

Material:	Natural Rubber+Steel	Color:	Black
Package:	Neutral Brown Carton Packaging	Function:	Shock Absorption
Overall Weight:	7.5KG	Package Size:	33 X 33 X 22 Cm
Goodyear:	3B12-304
Highlight:	Goodyear Triple Bellow Air Spring , Contitech Air Lift Bags , Industrial Air Spring with warranty

Goodyear 3B12-304 Triple Bellow Air Spring

Original Goodyear Triple Bellow Air Spring FT 330-29 430 Contitech Air Lift Bags designed for heavy-duty suspension applications.

Manufacturer & Identification

Original Manufacturer: GOODYEAR

OEM Numbers: 3B12-304, 3B 12-304

Bellow Numbers: 578-93-3-100, 578 93 3 100, 578933100

Compatible Replacement Models

CONTI 64568
CONTI FT330-29 503
CONTI FT 330-29 503
FIRESTONE 8006
FIRESTONE W01-358-8006
FIRESTONE W01 358 8006
FIRESTONE W013588006
LOAD GUARD SC132
SUSPENSION INC. 200620
TRIANGLE 4430
TRIANGLE 4503
TRP ASP1710

Technical Specifications

Top Plate Hole/Stud Quantity: 2

Top Plate Diameter: 9

Top Plate Center to Center Diameter: 6.2

Bottom Plate Hole/Stud Quantity: 2

Bottom Plate Diameter: 9

Bottom Plate Center to Center Diameter: 6.2

Bottom Plate Alignment: Parallel

Bumper: No

Bracket: No

Minimum Height: 4.8

Maximum Height: 18

Goodyear Air Spring Compatibility Chart

Part Number	Top Plate Hole/Stud Qty	Bottom Piston Hole/Stud Qty	Top Plate Dia	Bottom Plate Dia.	Collapsed Height	Flexmember	Piston	Piston Type
3B12-310	2	2	9	9	4.5	578-93-3-100	--	--
3B12-319	2	2	9	9	4.5	578-93-3-100	--	--
3B12-328	2	2	9	9	4.5	578-93-3-100	--	--
3B12-329	2	2	9	9	4.5	578-93-3-100	--	--
3B12-335	2	2	9	9	4.5	578-93-3-100	--	--
3B12-300	2	2	9	9	5.1	578-93-3-100	--	--
3B12-303	2	2	9	9	5.1	578-93-3-100	--	--
3B12-315	2	2	9	9	5.1	578-93-3-100	--	--
3B12-324	2	2	9	9	5.1	578-93-3-100	--	--
3B14-452	2	2	11.3	11.3	4.9	556-33-8-335	--	--
3B12-312	2	4	9	9	4.5	578-93-3-100	--	--
3B12-322	2	4	9	10.3	4.6	578-93-3-103	--	--
3B12-323	2	4	10.3	10.3	4.6	578-93-3-103	--	--
3B14-364	2	4	11.3	11.3	4.9	578-93-3-350	--	--
3B14-451	2	4	11.3	11.3	4.9	556-33-8-335	--	--
3B14-367	2	4	11.3	11.3	6	578-93-3-350	--	--
3B12-304	3	2	9	9	4.7	578-93-3-100	--	--
3B12-301	3	2	9	9	5.1	578-93-3-100	--	--
3B12-325	3	2	10.3	10.3	4.5	578-93-3-103	--	--
3B12-326	3	2	10.3	10.3	4.5	578-93-3-103	--	--
3B14-354	5	4	11.3	11.3	4.7	578-93-3-350	--	--
3B14-360	5	4	11.3	11.3	4.7	578-93-3-350	--	--
3B14-361	5	4	11.3	11.3	4.7	578-93-3-350	--	--
3B14-356	5	4	11.3	11.3	4.9	578-93-3-350	--	--
3B14-359	5	4	11.3	11.3	4.9	578-93-3-350	--	--
3B14-351	5	4	11.3	11.3	7.3	578-93-3-350	--	--
