FT960-34 RS Contitech Air Bellows Replacement W01-358-7761 Firestone Industrial Air Spring

Product Details:

Place of Origin:	China
Brand Name:	GUOMAT
Certification:	ISO/TS16949:2009
Model Number:	2B7761

Payment & Shipping Terms:

Minimum Order Quantity:	6pcs
Price:	US$399.9-499.9/PC
Packaging Details:	Strong Carton Box Or As Customers Need
Delivery Time:	3-7 Working Days
Payment Terms:	L/C,D/A,D/P,T/T
Supply Ability:	1000pcs/week

Contact Now

Detailed Product Description

Product Name:	Rubber Air Spring	Fitment Type:	Direct Replacement
Usage:	For Punching Equipment	Warranty:	12 Months Warranty
Spring Material:	High Quality Rubber	Contitech:	FT960-34RS
Color:	Black	MOQ:	6pcs
Highlight:	Contitech air spring replacement , Firestone industrial air bellow , Rubber air spring with warranty

FT960-34 RS Contitech Air Bellows Replacement W01-358-7761 Firestone Industrial Air Spring

High-quality replacement air spring designed to match OEM specifications for industrial applications.

Product Identification

GUOMAT NO.: 2H7761
CONTITECH: FT960-34RS, FT 960-34RS, FT 960-34 RS
FIRESTONE: W01-358-7761, W01 358 7761, W013587761

Technical Specifications

Flange diameter: 15.12 inches
Maximum outer diameter: 18.2 inches
Bolts: 18 x 3/8-24 UNF
Bolt center-to-center distance: 13.8 inches
Maximum height: 17.7 inches
Minimum height: 4.5 inches
Minimum pressure: 0 psi
Return force to minimum height: ≤135 lbs
Overall weight with bead rings, bolts, nuts and washers: 21 lbs
Design height H: recommended 13 in, minimum 12.4 in

Performance Data - Design Height 13 inches

Pressure (psi)	40	60	80	100	120	Volume (in³)
Force (Load) (lbs)	5770	8650	11530	14420	17300	2125
Spring Rate (lbs/in)	1144	1659	2079	2610	3029
Natural Frequency (Hz)	1.4	1.3	1.3	1.3	1.3

Force vs Height Performance

Height H (in)	20 psi	40 psi	60 psi	80 psi	100 psi	120 psi	Volume (in³)
15	2420	4830	7250	9670	12080	14500	2368
13	2880	5770	8650	11530	14420	17300	2125
11	3270	6530	9800	13070	16330	19600	1846
9	3560	7130	10690	14250	17820	21380	1511

Packaging & Delivery

Each GUOMAT air bellows is carefully packaged to protect the rubber body and metal components during transportation.

Individual protective poly bag
Carton packaging
Product number and quantity marked on the carton
Customized packaging available upon request
Customer logo and product marking available for OEM orders

GUOMAT can arrange international shipping by air freight, sea freight, express delivery, or other suitable transportation methods according to order quantity and destination.

Warranty

GUOMAT provides a 12-month / 1-year warranty for this air suspension isolator under normal operating conditions. If a quality-related issue occurs during the warranty period, customers can contact our sales team for technical support and after-sales assistance.
