S-600-4/S-600-4 YOKOHAMA Air Spring Replace Press Machine Rubber Air Bag

Product Details:

Place of Origin:	GuangDong, China
Brand Name:	GUOMAT
Certification:	ISO/TS16949:2009
Model Number:	F-600-4

Payment & Shipping Terms:

Minimum Order Quantity:	6PCS
Price:	Negotiable
Packaging Details:	Strong Carton Box Or As Customers Need
Delivery Time:	2-8 work days
Payment Terms:	L/C,D/A,D/P,T/T
Supply Ability:	1000pcs/week

Contact Now

Detailed Product Description

Features:	With Waist Ring	Shock Absorber Type:	Gas-Filled
Warranty:	1 Year	Keywords:	Air Suspension Shock Absorber
Packing:	Neutral Box Or As Customers' Request	Temperaturerange:	-40°C To +70°C
Layer Number:	4 Convolution	YOKOHAMA:	S-600-4R
Highlight:	Yokohama air spring replacement , press machine rubber air bag , rubber air spring with warranty

S-600-4/S-600-4 YOKOHAMA Air Spring Replacement

The GUOMAT F-600-4 is a large-diameter rubber air spring designed as a direct replacement for YOKOHAMA S-600-4 / S-600-4 air springs. With a nominal diameter of approximately 600 mm, this industrial air bag provides reliable performance for equipment requiring precise lifting, lowering, vibration isolation, and shock absorption capabilities.

Product Specifications

GUOMAT No.: F-600-4
Reference: YOKOHAMA S-600-4 / S-600-4R
Type: Rubber Air Spring / Air Bag
Nominal Diameter: 600 mm
Application: Press Machine, Stamping Machine, Industrial Equipment
Function: Lifting, Lowering, Vibration Isolation, Shock Absorption
Construction: Reinforced Rubber Bellows with Metal Components
Size: Manufactured according to YOKOHAMA reference dimensions

Technical Data

Parameter	Value
Design Height (mm)	218
Max Height (mm)	363
Min Height (mm)	123
Common Maximum Travel (mm)	±90
Compression Max Outside Diameter (mm)	660
Effective Area (cm²)	2830
Volume (L)	59.9
Load (KN)	138.3
Dynamic Spring Constant (n/mm)	1285
Maximum Internal Frequency (Hz)	1.5
Maximum Internal Pressure (MPa)	0.69
Internal Pressure Failure (MPa)	3.9-4.9

Applications

The F-600-4 air spring is engineered for press machine lifting and lowering systems, stamping equipment, molding machinery, and other industrial applications requiring pneumatic force and vibration isolation. Compared with conventional mechanical springs, this air spring offers adjustable working pressure and enhances machine stability during repeated operating cycles.

GUOMAT Replacement Advantages

GUOMAT air springs are manufactured using reinforced rubber materials and durable metal components specifically for demanding industrial environments. We provide replacement air springs that match YOKOHAMA reference numbers, dimensions, and mounting requirements. OEM and customized air spring solutions are also available to meet specific customer specifications.

Packaging & Delivery

Each air spring is securely packaged to protect rubber bellows and metal components during transit. Standard export packaging or customized options are available. Delivery typically takes 3-7 working days for available stock items. Shipping options include DHL, FedEx, UPS, air freight, sea freight, or other requested methods.
