Dunlop Suspension 4 1/2X1 Air Shocks Cross PM/31041 NORGREN Bellow Cylinder

Product Details:

Place of Origin:	Guangdong, China
Brand Name:	GUOMAT
Certification:	ISO/TS16949, ISO9001
Model Number:	1B4.5X1P

Payment & Shipping Terms:

Minimum Order Quantity:	5
Price:	Negotiable
Packaging Details:	Strong Carton Box or as Customers Requirement
Delivery Time:	5-8 Working Days
Payment Terms:	L/C, D/A, D/P, Western Union
Supply Ability:	1000PCS/Week

Contact Now

Detailed Product Description

Model NO.:	1B4.5X1P	Function:	Reduce Shock
Trademark:	GUOMAT	After-sales Service:	1 Year
Type:	Gas-Filled	Cross References:	W01-358-4050
Minimum Height:	45 MM	Air Fitting:	3/8 BSP
Highlight:	Dunlop Suspension 4 1/2X1 Air Shocks , PM/31041 Air Shocks

Dunlop Suspension 4 1/2X1 Air Shocks Cross PM/31041 NORGREN Bellow Cylinder

Product Information

Cover Plate

Top Cover Plate Diameter: 110 mm
Screw Center Distance of Top Cover Plate: 93 mm
Bottom Cover Plate Diameter: 110 mm
Screw Center Distance of Bottom Cover Plate: 93 mm

Nut/Blind Nut

Top Cover Plate Screw(Nut) Tooth: 3×M6
Bottom Cover Plate Screw(Nut) Tooth: 3×M6

Gas Hole/Air Inlet/Air Fitting

Gas Hole: 3/8 BSP

Rubber Bellow

Rubber Bellow Natural Diameter: 114 mm
Minimum Height: 45 mm

Other OEM Number

Dunlop Pneuride	4 1/2" x 1, 4 1/2' x 1, 4 1/2 x 1
Firestone	W01-R58-4050, W01 R58 4050, W01R584050 WO1-R58-4050, WO1 R58 4050, WO1R584050
Dunlop Springride	SP2334, SP 2334, sp 2334, sp2334
Contitech	FS 44-5 DI, FS44-5 DI, FS 44-5DI, FS 44 5 DI FS44-5DI, FS44-5DI, FS445DI, FS 445 DI
Norgren	PM/31041, PM31041, PM 31041
Parker	9109400

With The Same Rubber Bellow Has Other Type Air Springs

DUNLOP OEM NO.	Dunlop Springride NO.	Firestone NO.	Rubber Bellow Dia(mm)	Cover Plate NO. (mm)	Min. H. (mm)	Nut/Blind Nuts Type	Air Intet	Screw Center Distance(mm)
4 1/2×1	SP 2008	W01-R58-4043	114	51	33	#	#	#
4 1/2×1	SP 2334	W01-R58-4050	114	110	45	3-M6	3/8 BSP	93
4 1/2×2	SP 2441	W01-R58-4051	114	110	65	3-M6	3/8 BSP	93
4 1/2×2	SP 1457	W01-R58-4076	114	110	53	#	#	#
4 1/2×3	SP 2895	W01-R58-4035	125	110	100	6-M6×12	G 3/8	93

Applications

Rubber actuators, compared with traditional products (rigid actuators, spring...) offer numerous advantages such as
Flexibility (no angle or alignment problem)
Compactness
Power / price ratio
No maintenance or lubrication required
Durability
Reliability
Resistance to aggressive or hot conditions

Support and Services

The Suspension Air Springs product technical support and services include:
Expert troubleshooting assistance to diagnose and resolve technical issues
Guidance on proper installation and maintenance procedures
Product documentation, including user manuals and technical specifications
Product training and education for customers and service technicians
Warranty and repair services, including replacement parts and exchange programs
Customer support for urgent technical issues or service needs

Company Profile

Guangzhou Guomat Air Spring Co., Ltd. is founded in 2008, the company covers an area of 20000 square meters, registered capital is 10 million yuan, the existing various types of professional and technical personnel is 85 people.The company is located in Guangzhou, about 15min's drive from Baiyun Airport. and our main products are air spring, rubber bellows, air suspension spring, air suspension compressor and refitted suspension system. They are widely used in bus, truck, cabin, vehicles' seat, luxurious car and industrial machine field.
