Contitech FD 614-26 Air Spring Suspension System For Pneumatic Applications

Product Details:

Place of Origin:	Guangdong, China
Brand Name:	GUOMAT
Certification:	ISO/TS16949, ISO9001
Model Number:	2B1426

Payment & Shipping Terms:

Minimum Order Quantity:	5
Price:	Negotiable
Packaging Details:	Strong Carton Box or as Customers Requirement
Delivery Time:	5-8 Working Days
Payment Terms:	L/C, D/A, D/P, Western Union
Supply Ability:	1000PCS/Week

Contact Now

Detailed Product Description

Model NO.:	2B1426	Structure:	Double Convoluted
Function:	Reduce Shock	Quality:	100% Tested
Part:	Air Spring	Operation:	Gas-Filled
Minimum Height:	75 MM	Maximum Height:	340 MM
Highlight:	Contitech FD 614-26 Air Spring , Pneumatic Suspension Air Spring

Contitech FD 614-26 Air Spring Suspension System For Pneumatic Applications

Product Information

Bottom Cover Plate

Alignment: Parallel
Center To Center Diameter: 282.5 mm
Diameter: 310 mm
Hole Quantity: 4
Type: Steel

Top Cover plate

Alignment: Parallel
Center To Center Diameter: 282.5 mm
Diameter: 310 mm
Hole Quantity: 5
Type: Steel

Rubber Bellow

Maximum Diameter: 400 mm
Expanded Height: 75 mm
Compressed Height: 340 mm
Spring Type: Double Convoluted

Air Inlet/Air Hole/Gas Hole/Gas Fitting

Type: 1/2 BSP

Nut/Blind Nuts

Type: 4×M10

Cross References

Contitech Part Number

FD614-26

FD 614-26

FD614-26 DS

FD 614-26 DS

FD614-26 DS G1/2

FD 614-26 DS G1/2

Contitech Model Series D Type Air Spring

Single Convoluted Bellows
FS 22-3 DI CR	2 3/4X1
FS 44-5 DI CR	4 1/2X1
FS 76-7 DI CR	6X1
FS 76-7 DS CR	6X1
FS 138-8 DS	8X1
FS 210-10 DS	10X1
FS 412-10 DS	12X1
FS 614-13 DS	14X1
FS 916-15 DS	16X1

Double Convoluted Bellows
FD 22-4 DI CR	2 3/4X1
FD 44-10 DI CR	4 1/2X1
FD 76-14 DI CR	6X2
FD 76-14 DS CR	6X2
FD 138-18 DS	8X2
FD 209-21 DS	9 1/4X2
FD 210-22 DS	10X2
FD 412-18 DS	12X2
FD 614-26 DS	14X2
FD 816-30 DS	16X2

Triple Convoluted Bellows
FT 22-6 DI CR	2 3/4X3
FT 44-15 DI CR	4 1/2X3
FT 76-20 DI CR	6X3
FT 76-20 DS CR	6X3
FT 138-26 DS	8X3
FT 210-32 DS	10X3
FT 412-32 DS	12X3
FT 614-36 DS	14X3
FT 816-40 DS	16X3

Advantages of GUOMAT Air Spring

Enhanced Durability: Built with reinforced rubber and steel components, the FD 614-26 air spring is highly resistant to wear, corrosion, and extreme environmental conditions.
Optimal Shock Control: The advanced technology within the Contitech FD 614-26 effectively minimizes vibrations and impact forces for smoother operation.
Extended Service Life: Ensures long-term reliability, reducing routine maintenance costs and downtime.
Wide Compatibility: The product can seamlessly integrate into a variety of systems, thanks to its compatibility with multiple OEM parts.
