FS 200-10 Contitech Convoluted Air Spring SP1B12 Phoenix Suspension Air Bags

Product Details:

Place of Origin:	GuangDong, China
Brand Name:	GUOMAT
Certification:	ISO/TS16949:2009
Model Number:	1B20010-G3/4-M8

Payment & Shipping Terms:

Minimum Order Quantity:	6PCS
Price:	$59.9-69.9/pc
Packaging Details:	Strong Carton Box Or As Customers Need
Delivery Time:	2-8 work days
Payment Terms:	L/C, T/T, Western Union
Supply Ability:	1000pcs/week

Contact Now

Detailed Product Description

Material:	Rubber+Steel	Warranty:	1 Year
Type:	Gas-filled	Gas Hole Type:	G3/4
Threaded Hole:	M8	Firestone:	W01-M58-6374
Norgren:	PM/31091	Contitech:	FS200-10
Highlight:	SP1B12 Phoenix Suspension Air Bags , Contitech Phoenix Suspension Air Bags , FS 200-10 Convoluted Air Spring

FS 200-10 Contitech Convoluted Air Spring SP1B12 Phoenix Suspension Air Bags

Key Specifications

Parameters	Details
Brand	GUOMAT
Model Number	1B20010-G3/4-M8
Interface Type	G3/4 thread + M8 bolt
Temperature range	-30°C to +70°C
Material	High-quality rubber + reinforced fiber layer + galvanized metal parts
Warranty	1 Year
Keywords	Air Spring,Suspension Air Spring

GUOMAT 1B20010 air spring is designed for harsh working conditions, providing excellent shock absorption and long life. It replaces the same model of Firestone and Contitech, with a 30% reduction in cost and 100% compatibility verification.

Precise adaptation: G3/4 threaded interface + M8 bolt, perfectly matching the original vehicle installation position.
Durable material: UV-resistant rubber + rust-proof metal parts, suitable for high load and humid environment.
Performance guarantee: XX certification (such as ISO 9001), pressure test report can be provided.

"Suitable for trucks, trailers, industrial equipment suspension systems, especially recommended for long-distance transportation and mining machinery, reducing bumps and losses and improving driving comfort.

This Part can Replace the Following Original Models

Firestone OEM Number: W01-M58-6374 / WO1-M58-6374

Firestone OEM Number: W01 M58 6374 / WO1 M58 6374

Firestone OEM Number: W01M586374 / WO1M586374

Contitech OEM Number: FS200-10

Contitech OEM Number: FS 200-10

Contitech OEM Number: FS200-10 CI

Contitech OEM Number: FS 200-10 CI

Phoenix OEM Number: SP1B12

Phoenix OEM Number: SP 1B 12

Dunlop (FR) OEM Number: 9''1/4X1 S09101

Bosch OEM Number: 822419004

Festo OEM Number: EB-250-85

Norgren OEM Number: PM/31091(8 1/4X1)

Purchase Order Data

Type	Order No.
with G3/4 air inlet M8X1.25 Threaded Hole A = 38.0 mm excentrical	1B20010-G3/4-M8
with G1/4 air inlet M10X1.5 Threaded Hole A = 44.5 mm excentrical	1B20010-G1/4-M10
with 1/4NPTF air inlet 3/8-16UNC Threaded Hole A = 44.5 mm excentrical	1B20010-1/4NPTF-3/8
with 3/4NPT air inlet 3/8-16UNC Threaded Hole A = 38.0 mm excentrical	1B20010-3/4NPTF-3/8
