2B12-324 Goodyear Convoluted Gas-Filled Air Bellow W01-358-7447 Firestone Rubber Air Suspension

Product Details:

Place of Origin:	Guangzhou,China
Brand Name:	GUOMAT
Certification:	ISO/TS16949:2009
Model Number:	2B7447

Payment & Shipping Terms:

Minimum Order Quantity:	5pcs
Price:	USD59.9-69.9/PC
Packaging Details:	Strong Carton Box or as Customers Requirement
Delivery Time:	3-7 Working Days
Payment Terms:	L/C, T/T, Western Union Or Others
Supply Ability:	1000PCS/Week

Contact Now

Detailed Product Description

Item Name:	Air Suspension Spring \| Customized Request	Material:	Natural Rubber+Steel Cover Plate
Warranty:	1 Year	Other Name:	Air Spring,Air Bags,Air Mount
Goodyear:	2B12-324	Firestone:	W01-358-7447
Usage:	For Truck And Trailer	Directory:	Suspension System
Highlight:	Goodyear gas-filled air bellow , Firestone rubber air suspension , convoluted air spring with warranty

2B12-324 Goodyear Convoluted Gas-Filled Air Bellow W01-358-7447 Firestone Rubber Air Suspension

2B12-324 Goodyear Convoluted Gas-Filled Air Bellow W01-358-7447 Firestone Rubber Air Suspension

Product Specification

Item	Value
Brand	GUOMAT
OEM.NO.	2B7447
Warranty	12 Months
Truck Model	Heavy Duty Truck
Color	Black
Place of Origin	Guangzhou,China
Certification	ISO/TS16949:2009
Material	Rubber+Steel
Packing	Neutral Packing
MOQ	1 Pcs
Quality	High-Quality
Position	Auto/Truck parts
Application	Auto Suspension Systems

Product Parameters

Maximum Height: 12.4"
Minimum Height: 3.8"
Cover Plate Diameter: 9.0"
Center Distance on the Top Cover Plate: 5.5"
Center Distance on the Bottom Cover Plate: 6.2"

OE Manufacturer Number

AUTOMANN: ABSP2B22RA-7447
AUTOMANN: ABSP2B22RA-7790
CONTITECH: 64532
CONTITECH: FD 330-30 340 / FD330-30 340
DAYTON: 354-7447
E-Z RIDE: 8030150
FIRESTONE: 7447
FIRESTONE: 7790
FIRESTONE: W01-358-7447 / W01 358 7447 / W013587447
FIRESTONE: W01-358-7790 / W01 358 7790 / W013587790
HENDRICKSON: 1475
HENDRICKSON: B-6242
INT'L/NAVISTAR: 554790C1
LOAD GUARD: SC2028
TRIANGLE: 4340
TRIANGLE: 4513

W01-358-7447 Firestone Air Spring

Top Plate Diameter: 9.00
Piston Diameter: 9.00
Bellows Diameter: 12.00
Minimum Compressed Height: 3.70
Air Inlet Height: 1.35
Top Plate Mounting Type: Air Inlet
Piston Mounting Type: Threaded Hole
Piston Threaded Hole Quantity: 2
Distance Between Piston Threaded Holes: 6.20
Has Inner Bumper: Yes
Bellows Number: 22-1.5

Company Profile

Guangzhou Guomat Air Spring Co., Ltd. is founded in 2008, the company covers an area of 20000 square meters, registered capital is 10 million yuan, the existing various types of professional and technical personnel is 85 people.The company is located in Guangzhou, about 15min's drive from Baiyun Airport. and our main products are air spring, rubber bellows, air suspension spring, air suspension compressor and refitted suspension system. They are widely used in bus, truck, cabin, vehicles' seat, luxurious car and industrial machine field.
