Torpress Model 131 Rubber Air Bellows 94047 Industrial Air Spring Assembly With 1/4''NPTF

Product Details:

Place of Origin:	GuangDong, China
Brand Name:	GUOMAT
Certification:	ISO/TS16949:2009
Model Number:	94047

Payment & Shipping Terms:

Minimum Order Quantity:	6PCS
Price:	US$59.9-69.9/PC
Packaging Details:	Strong Carton Box Or As Customers Need
Delivery Time:	2-8 work days
Payment Terms:	L/C,D/A,D/P,T/T
Supply Ability:	1000pcs/week

Contact Now

Detailed Product Description

Type:	Industrial Air Spring	Material:	Natural Rubber
Refer No:	Torpress 94047	Spring Weight:	1.6KG
Origin:	China	Port Size:	1/4NPTF
Part Name:	Rubber Air Spring	Convolutions:	1
Highlight:	Rubber Air Bellows 94047 , Industrial Air Spring Assembly , 1/4''NPTF Air Spring

Product Overview

The Torpress Model 131 Rubber Air Bellows 94047 is a single convoluted industrial air spring assembly manufactured by GUOMAT. Built with a reinforced rubber bellows and steel end plates, it delivers reliable load support, vibration isolation, and shock absorption for industrial machinery, punch presses, and suspension systems. The assembly features a 1/4'' NPTF threaded air inlet for precise pressure control.

Key Specifications

Type	Single Convoluted Air Spring
Brand	GUOMAT
Model No.	94047
Material	Rubber, Steel
Warranty	1 Year

Common Cross-References

Pirelli Torpress

Model Number: 131
Part Number: 94047

Firestone

Style Number: 131
Part Number: W01-358-7731
Part Number: W01 358 7731
Part Number: W013587731

Technical Data

Connection	Cover Plate
Max. Outer Diameter	165 mm
Min. Height	50 mm
Max. Height	110 mm
Static Height	85 mm
Thread Air Hole	1/4'' NPTF
Center Distance	44.5 mm
Cover Plate Diameter	114.5 mm
Connecting Bolts / Holes	2 PCS × 3/8''-16 UNC
Cover Plate Height	16 mm
Effective Area	95 cm²
Load Capacity	665 daN
Frequency	185 cicli/1'
Stiffness	14.5 daN/mm

What Is a Rubber Air Spring?

A rubber air spring is a flexible pneumatic component that uses compressed air to provide load support, vibration isolation, and shock absorption. It typically consists of a reinforced rubber bellows, metal end plates, and mounting components. By adjusting the internal air pressure, the spring delivers variable load capacities and working heights. Rubber air springs are widely used in industrial machinery, punch press machines, vehicle suspension systems, and vibration isolation equipment.

Single Convoluted Air Spring Series

Model	Standard Code	High-Temp Code	Connection	Max. OD (mm)	Min. Height (mm)	Max. Height (mm)	Static Height (mm)	Effec. Area (cm²)	Cap. (daN)	Freq. (cicli/1')	Stiffness (daN/mm)
16	93029	93086	P1	153	46	91	70	86	600	250	21
131	94047	--	P1	165	50	110	85	95	665	185	14.5
110	93113	93114	P1	210	51	151	101	180	1260	154	18.8
88540	93079	--	F1	210	45	145	95	180	1260	154	18.8
88820	89023	--	F1	210	45	145	95	180	1260	154	18.8
116	93027	--	P1	231	46	152	100	180	1260	165	20.5
19	94016	95015	P2	325	51	151	127	450	3150	158	41.5
94014	--	--	F2	325	43	143	127	450	3150	158	41.5
